As a specialized manufacturer in polymer materials, Shanghai Yunshan Plasticizing Co., Ltd. proudly presents our premium PA66 Celanese 101L NC010 Nylon Resin. This engineering-grade material is meticulously formulated to deliver exceptional performance in demanding injection molding applications. We understand that our B2B clients require reliability, consistency, and value, and this resin is engineered to meet those precise needs, offering a robust combination of mechanical integrity, thermal resistance, and excellent processability to enhance your manufacturing outcomes.
Our PA66 101L NC010 resin is characterized by several distinct advantages that translate directly into benefits for your production line and final products.
- Superior Mechanical Performance: Provides high tensile strength, stiffness, and outstanding resistance to impact and wear, ensuring durable components that withstand rigorous use.
- Excellent Thermal Stability: Maintains its properties across a wide temperature range, making it suitable for under-the-hood automotive parts and electrical applications where heat resistance is critical.
- Enhanced Processability: Designed for smooth injection molding with good flow characteristics, which can lead to shorter cycle times, reduced waste, and improved surface finish on molded parts.
- Dimensional Stability: Exhibits low moisture absorption compared to other nylons, resulting in parts with consistent dimensions and reliable performance in varying humidity conditions.
- Chemical Resistance: Offers good resistance to oils, greases, and many solvents, broadening its application scope in industrial environments.
The technical specifications below provide a clear overview of the material's key properties. Please note that values are typical and may vary based on specific processing conditions.
| Property | Test Method | Typical Value |
| Tensile Strength | ISO 527 | 80 MPa |
| Flexural Modulus | ISO 178 | 2800 MPa |
| Notched Izod Impact | ISO 180 | 5 kJ/m² |
| Melting Point | ISO 11357 | 260 °C |
| Density | ISO 1183 | 1.14 g/cm³ |
This resin is ideally suited for manufacturing high-performance components across various sectors:
- Automotive: Engine covers, radiator end tanks, intake manifolds, and connectors.
- Electrical & Electronics: Circuit breakers, connectors, switches, and coil bobbins.
- Industrial: Gears, bearings, rollers, and housings for machinery.
- Consumer Goods: Power tool housings, sporting goods, and functional appliance parts.
Operating from our base in Shanghai, a global hub for trade and manufacturing, Shanghai Yunshan Plasticizing Co., Ltd. leverages strategic logistics and a deep understanding of the Asian polymer market to serve our clients. Our commitment is to supply consistent, high-quality materials like the PA66 101L NC010 resin, supporting your projects from prototype to full-scale production. We invite you to experience the reliability and performance this material brings to your injection molding operations. Contact us today to discuss your specific requirements, request samples, or to learn more about how our solutions can add value to your supply chain.
Frequently Asked Questions (FAQ)
Q1: Is this PA66 resin suitable for food contact applications?
A: The Celanese 101L NC010 grade is a standard, natural-colored resin. It is not specifically certified for food contact. For applications requiring food-grade compliance, please inquire about alternative grades that meet relevant standards.
Q2: What are the recommended drying conditions before processing?
A: Like most PA66 materials, this resin is hygroscopic. We generally recommend drying at 80-90°C for 4-6 hours prior to injection molding to achieve optimal moisture content (typically below 0.2%) and prevent potential defects like splay or reduced mechanical properties.
Q3: Can this material be colored or compounded with additives?
A: Yes, the natural color of the 101L NC010 pellets makes it an excellent base for coloring. Masterbatches can be added during processing. We can also discuss custom compounding services to incorporate additives like glass fibers, flame retardants, or stabilizers upon request.
Q4: What is the typical mold shrinkage for this grade?
A: Mold shrinkage for unfilled PA66 can vary with part design and processing parameters. Typical shrinkage values range between 1.5% and 2.0%. Detailed processing guidelines, including shrinkage data, are available from our technical support team.
Q5: How does it compare to PA6 or other nylons?
A: PA66 generally offers higher temperature resistance, better stiffness, and lower moisture absorption compared to PA6. It is often chosen for more demanding mechanical and thermal applications. Our team can help you select the right nylon grade based on your specific performance needs.
Q6: What is the minimum order quantity (MOQ)?
A: Our standard MOQ is one pallet, but we are flexible and can accommodate various order sizes to meet customer needs. Please contact our sales department for precise MOQ and pricing details tailored to your location and volume.
Q7: Do you provide technical data sheets and processing guides?
A: Absolutely. Comprehensive technical data sheets (TDS) and safety data sheets (SDS) are available for download or can be sent directly upon request. We also offer processing advice to help optimize your molding parameters.
Q8: What is the lead time for delivery?
A: For standard grades like 101L NC010, we often maintain stock for prompt dispatch. Lead times can vary based on order quantity and destination. We strive to provide accurate delivery timelines upon order confirmation.
