Hydraulic Knuckle Boom Marine Crane Deck Crane

Shanghai Guanhai Engineering Co.,ltd

Hydraulic Knuckle Boom Marine Crane Deck Crane thumbnail-1

Hydraulic Knuckle Boom Marine Crane Deck Crane thumbnail-2

Hydraulic Knuckle Boom Marine Crane Deck Crane thumbnail-3

Hydraulic Knuckle Boom Marine Crane Deck Crane photo-1

Hydraulic Knuckle Boom Marine Crane Deck Crane photo-2

Hydraulic Knuckle Boom Marine Crane Deck Crane photo-3

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

GHE

Place of Origin:

China

Model Number:

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name GHE

Place of Origin China

Standard equipment:

Shot blasted to SA2, 5 plus 2 layers of marine paint

Pedestal height between 1.1 and 1.5m

Class certificate on the pedestal

Control platform on the crane(left or right-hand side)

Full documentation/owner's manual

Working radius and lifting capacity(SWL ACCORDING TO CUSTOMER'S REQUEST

Technical Parameters:

Please kindly check below tables

As a professional manufacturer of marine crane, truck mounted crane, we are always specialised in developing and researching heavy equipment, especially on the quality and after-sale service, unless, we also provide you with reparing technology, clear up your worry without anyone can repair when it cannot work. Even if you did not buy from us, we also can serve for you..

Model	Unit	KT001	KT002	KT003	KT004	KT005	KT006	KT007	KT008
Lifting Moment	KN. M	38.77	58.15	77.7	83.8	126.5	137.4	173.4	214
Max lifting moment	KN. M	53.29	80.12	104.3	117.6	173.8	190.5	246.4	295
Max outreach	M	4.5	5.35	5.38	5.8	6.06	6.03	6.1	8
Slewing angle	DEGREE	400	422	373	417	426	426	409	409
Max rotation torque	KN. M	15.98	16.24	16.14	16.4	25.37	25.37	51.7	44.43
Volume of oil tank	L	20	40	40	45	70	85	115	150
Max working Pressure	BAR	195	220	210	230	230	230	210	250
Pump delivery	L/MIN	20	25	30	35	40	40	40	45
Max. power	KW/CV	7.64/10.39	10.78/14.6	12.35/17	15.7/21.4	18/24.5	18/24.5	16.5/22.4	23/31.2
Weight	kg	730	915	1057	1115	1590	1810	2475	2850
