Fiber Fault Locator FFL-304

Description

Handheld fiber optic visual fault locator, handheld, single wavelength, 9/125um SM fiber, 1550±20nm, max 100mW output power, max 60km distance,LCD display, FC adaptor

Features
1. End-to-end visual fiber identification
2. Locates faults up to 60km along the fiber.
3. Mechanical fusion splice optimization
4. Compact size and light weight, suitable for field testing
5. Detects breaks, micro-bends even through jacketed fibers

Parameter

Item Specification

Recognizable wavelength range 900 to 1650nm

Recognizable signal type CW, 2kHz, 1kHz, 270Hz ±5%

Detector Type InGaAs 2pcs

Clamp Type H0.9/0.25 for bare fibers ; H2.5 for jacketed fiber

Sensitivity @ 1310nm +11dB to-20 dBm (Continuous Wave) ;

+11dB to-10 dBm (Modulated Signal)

@ 1550nm +11dB to-30 dBm (Continuous Wave) ;

+11dB to-18 dBm (Modulated Signal)

LED Indicator signal traffic; signal frequency(2kHz/1kHz/270Hz);  signal intensity (5 grades) ; low battery

Operating temperature -10 to +50

Storage temperature -20 to+70

Power Supply 1.5V AA batteries*2pcs

Dimension  202L*62W*36H mm

Weight  270 g

Application

FTTH, LAN, PON & Optical CATV

Local ring net

Optical fiber communication system

Optical fiber test equipment

Optical fiber sensor

Dimension

202L*62W*36H mm

Minimum Order

1pcs
