Optical Light Source OLS-109

Description

Handheld mini optical light source(fiber optic light source), handheld, dual wavelength, 1310/155010nm, -7dBm output power, LCD display, FC connector

Features
1. High stability of the output power
2. Stable output wavelength
3. Backlight LCD display supports night operation
4. Compact size and decent appearance
5. Large LCD, easy operation
6. Provides 2 output wavelengths which Can be optional according to customer's needs
7. CW, 2Hz modulation output at 650nm, and CW, 270Hz, 1KHz, 2KHz modulation output at other wavelengths

Parameter

Item Specification

Wavelengths 1310/1550 nm

Emitter type FP-LD,LED or others please specify

Typical output power -7dBm for LD, -20dBm for LED

Spectral width 1.     ≤ 10 nm

Output stability ±0.05dB/15mins;   ±0.1dB/ 8hours

Modulation frequencies CW,270Hz,1KHz,2KHz

Optical connector FC/PC

Power supply Alkaline Battery (3 AA 1.5V batteries)

Battery operating time 45 hour

Operating temperature -10~+60

Storage temperature -25~+70

Dimension 175x82x33 mm

Weight 295 g

Application

FTTH, LAN, PON & Optical CATV

Local ring net

Optical fiber communication system

Optical fiber test equipment

Optical fiber sensor

Dimension

175x82x33 mm

Minimum Order

1pcs

Weight

295 g

Delivery Time

5~7days

Packaging

By standard export carton

Supply Ability

1000pcs/month
