Optical Fiber Identifier OFI-3

Description

Optical fiber identifier(fiber optic identifier), portable, designed to detect optical signals without disrupting traffic, suitable for 0.25, 0.9 and 3.0mm jacketed fiber, clamping trigger design, outdoor and indoor use. Price for 1310 or 1550nm.

Features
1. Displaying signal intensity
2. Low battery reminder
3. Concise LED light
4. Powered by 2 units of 1.5V AA alkaline batteries
5. RB0.25mm, RB0.9mm, RB3.0mm plungers available
6. Easy and convenient operation with a single keystroke
7. Detect a variety of optical tones, 270Hz, 1KHz and 2KHz
8. Interchangeable adapter heads (clamps) for bare and jacketed fiber

Parameter

Item Specification

Recognizable wavelength range 900 to 1650nm

Recognizable signal type CW, 2kHz, 1kHz, 270Hz ±5%

Detector Type InGaAs 2pcs

Clamp Type H0.9/0.25 for bare fibers ; H2.5 for jacketed fiber

Sensitivity @ 1310nm +11dB to-20 dBm (Continuous Wave) ;

+11dB to-10 dBm (Modulated Signal)

@ 1550nm +11dB to-30 dBm (Continuous Wave) ;

+11dB to-18 dBm (Modulated Signal)

LED Indicator signal traffic; signal frequency(2kHz/1kHz/270Hz);  signal intensity (5 grades) ; low battery

Operating temperature -10 to +50

Storage temperature -20 to+70

Power Supply 1.5V AA batteries*2pcs

Dimension  202L*62W*36H mm

Weight  270 g

Application

FTTH, LAN, PON & Optical CATV

Local ring net

Optical fiber communication system

Optical fiber test equipment

Optical fiber sensor

Dimension

202L*62W*36H mm

Minimum Order

1pcs

Weight

270 g

Delivery Time

5~7days

Packaging

By standard export carton

Supply Ability

1000pcs/month
