Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Optical Light Source OLS-4
Negotiable
MOQ: 1 Case (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
YOUXIN
Place of Origin:
China
Model Number:
OLS-4
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Brand Name
YOUXIN
Place of Origin
China
Model Number
OLS-4
Optical light source, handheld, dual wavelength, 1310/1550nm, output -5dBm, operates in either continuous wave (CW) mode or 2kHz modulated mode.
Features: Download DOC:![\"OLS-4]()
OLS-4 Laser Source
◇ Easy-to-use, straight forward operation
◇ Pocket size, Rugged, compact and lightweight
◇ Offer excellent stability and portability for fiber optic testing
◇ Powered by a 9V laminated battery or AC adaptor
◇ The compact unit operates in either continuous wave(CW) mode or modulated mode
◇ Interchangeable fiber-optic adapters
◇ Reliable basic functionality for most economical testing
◇ Auto-off function: saves the power and low power consumption allows extended operation in the field
◇ Three-year warranty and recommended calibration interval
Description
The OLS-4 series Laser Source offer excellent stability and portability for fiber optic testing. Single output port provides stable laser power at dual-wavelength (1310nm&1550nm). The compact unit operates in either continuous wave (CW) mode or modulated mode.
We provide both single mode and multimode wavelengths for varies of application. When used with YOUXIN Optical power meter, it will performing optical loss measurements on fiber optic cables easily.
Parameter
|
Item
|
Specification
|
|
|
Output wavelength
|
1310&1550+ 20 nm
|
|
|
Emitter type
|
LD
|
|
|
Screen
|
N/A
|
|
|
Output stability
|
Short Term (15 min.): < ±0.05dB @1310,1550nm; ±0.1dB@other wavelengths
Long Term (8 Hours ): < ±0.1dB @1310,1550nm;±0.2dB@other wavelengths
|
|
|
Spectral width
|
5 nm
|
|
|
Output frequency
|
2K Hz
|
270,1K,2K Hz
|
|
Output power
|
5dBm
|
|
|
Optical connector
|
FC connector
|
|
|
Operating temperature
|
-10 to +50 ℃
|
|
|
Storage temperature
|
-20 ~ +70℃
|
|
|
Power supply
|
9V laminated battery
|
|
|
Dimension
|
130x69x22 mm
|
|
|
Weight
|
180g
|
Applications
◇ Optical Communication
◇ CATV
◇ Optic Fiber Project
