PON Optical Power Meter OPM-212P

Description

PON optical power meter, 1260~1360/1480~1500/1539~1565nm, 1310/1490nm 2 calibrated wavelength, dynamic range - 40 ~ +10dBm(1550nm dynamic range -40 ~ +20dBm), hand held, SC adaptor...

Features
1. User self calibration function
2. Comfortable LCD display and optional
Backlight LCD display supports night operation
3. Power measurements in dBm or mW and
Insertion loss in dB
4. Low battery consumption, more than 240 hours
Continual operation time for three 1.5V alkaline batteries
5.10 minutes Auto-off function can be open or shut off

Parameter

Item Specification

1310nm upstream measurement

Pass zone 1260~1360 nm

Isolation @1490/1550nm >40 dB

Measurement range -40~+10 dBm

1490nm downstream measurement

Pass zone 1470~1505 nm

Isolation @1550nm >30 dB

Isolation @1310nm >40 dB

Measurement range -40~+10 dBm

1550nm downstream measurement

Pass zone 1535~1570 nm

Isolation @1490nm >40 dB

Isolation @1310nm >40 dB

Measurement range -40~+20 dBm

Measurement Accuracy

Connatural uncertainty ±0.5 dB

Linearity ±0.1 dB

Passing through insertion loss <1.5 dB

General Information

Display   Graphic display, Resolution is : 128*64

Measurement unit DBm, dB, mW, and uW

Resolution 0.01dB

Fiber Type 9/125um

Input power range DC 6.5V~8.5V

Rechargeable battery 7.4V

AC adaptor 8.4V

Operating temperature -10 ~ +60

Storage temperature -25 ~ +70

Dimensions 210X115X55 mm

Application

FTTH, LAN, PON & Optical CATV

Local ring net

Optical fiber communication system

Optical fiber test equipment

Optical fiber sensor

Dimension

210X115X55 mm

Minimum Order

1pcs

Weight

Delivery Time

5~7days
