Cuatom 2000L Shampoo Mixer Machine With Group Stainlesss Steel Blending Tanks
2000L group blending blending tank is mainly suitable for preparation of liquid detergents(such as shampoo, mouthwash, hand wash, liquid soap and so on) .Integrating blending ,dispersing, heating and cooling ect. Functions, the reacting machine is an ideal device for liquid preparation in various factories.
Configuration
(1) Material :316L stainless steel .
(2) Capacity :Solution volume range from 300-1000L.
(3) It can heat up the water to 80-90 degrees by Electric steam boiler.
(4) Add one centrifugal pump, to homogenize the material in re-circulation transfering,and make the cleaning more easier.
(5) Heating method:Steam heating.
(6) Install one 5 micron filter between the blending tank and storage tank.
(7) Add the weighing load cell ,Unit in “kg” with 2 decimals.
Parameter
|
No. |
Item |
Technical parameter |
Remark |
|
1 |
Top Blending |
Blending paddle, Power:4KW |
Frequency control of motor speed |
|
2 |
Operating status |
Normal pressure |
|
|
3 |
Empty method |
Stainless steel Butterfly valve |
6.7cm |
|
4 |
Cover open method |
Flexible cover |
|
|
5 |
Temperature display |
Pt100 type thermo detector |
|
|
6 |
Pressure display |
Non |
|
|
7 |
Heating and cooling method |
Steam heating , water cooling system |
With the Heat preservation layer |
|
8 |
Jacket operating pressure |
Non |
|
|
Jacket pressure |
≦100℃ |
||
|
Design volume |
1200L |
||
|
Working capacity |
1000L |
||
|
9 |
Material:Inner layer |
SUS316L 6mm |
|
|
Jacket |
Q235-B 6mm |
||
|
Shell |
304 2mm |
||
|
10 |
Polishing |
Inner layer polishing reach 300EMSH |
|
|
11 |
Frame and platform |
4 handles |
|
|
12 |
Electric controller |
||
|
13 |
Power consumption |
Top blending power: 4KW |
|
|
14 |
|||
|
15 |
Blending structure |
Blending with paddle, one fixed guide plate, without the scraper |
