Home > Products > Wiring Duct > EASCO High Temperature Duct
EASCO High Temperature Duct
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | EASCO | Place of Origin | China | |
| Model Number | PXC |
Product Description
1)UL.CE.ROHS.REACH,Wire Duct
2)Wide Open Slot Cable Duct.Round slot :4mm to 8mm
3)Self-extinguishing PVC Wiring Cable Duct.
|
Desp: PVC Lead Free wiring duct , wide slot cable duct. Cable Management. |
| Material: Rigid PVC Material. Self-extinguishing.UL94 V-0 |
|
Length: 2 Meter (~78") |
|
Part No.: PXC |
FEATURES:
1)Aesthetics Open Slot Wiring Duct
2)Easy insertion and removal of wire and cable.
3)Smooth edges can protect your hands & wiring insulation free from burrs or
sharp edges without abrasion
4)With mounting holes for easy mounting.
5)Non-slip cover. Flush cover design holds more wires than traditional duct.
SPECIFICATIONS:
| Part No. | WxH | M/PACK | 14AWG/PCS |
| PXC1525 | 15X25 | 300 | 5-12 |
| PXC2025 | 20X25 | 232 | 5-12 |
| PXC2525 | 25X25 | 180 | 10-25 |
| PXC2030 | 20X30 | 192 | 15-25 |
| PXC2530 | 25X30 | 144 | 15-25 |
| PXC3030 | 30X30 | 120 | 15-25 |
| PXC3530 | 35X30 | 112 | 25-30 |
| PXC4030 | 40X30 | 100 | 25-35 |
| PXC3333 | 33X33 | 124 | 20-30 |
| PXC2535 | 25X35 | 144 | 15-25 |
| PXC3535 | 35X35 | 120 | 40-45 |
| PXC5035 | 50X35 | 100 | 55-65 |
| PXC2540 | 25X40 | 124 | 20-25 |
| PXC4040 | 40X40 | 80 | 60-70 |
| PXC6040 | 60X40 | 80 | 100-115 |
| PXC2545 | 25X45 | 128 | 20-25 |
| PXC3345 |
33X45 |
84 | 40-55 |
| PXC4545 | 45X45 | 92 | 60-70 |
| PXC6545 | 65X45 | 72 | 80-90 |
| PXC2550 | 25X50 | 100 | 20-25 |
| PXC3050 | 30X50 | 120 | 30-35 |
| PXC3550 | 35X50 | 120 | 40-45 |
| PXC4050 | 40X50 | 100 | 50-60 |
| PXC4550 | 45X50 | 80 | 60-70 |
| PXC5050 | 50X50 | 80 | 80-90 |
| PXC5550 | 55X50 | 72 | 80-90 |
| PXC6050 | 60X50 | 68 | 85-95 |
| PXC8050 | 80X50 | 52 | 150-170 |
| PXC10050 | 100X50 | 40 | 200-240 |
| PXC2560 | 25X60 | 132 | 40-45 |
| PXC3560 | 35X60 | 108 | 40-55 |
| PXC4060 | 40X60 | 96 | 100-115 |
| PXC4560 | 45X60 | 84 | 113-118 |
| PXC5560 | 55X60 | 72 | 115-130 |
| PXC6060 | 60X60 | 60 | 120-135 |
| PXC8060 | 80X60 | 44 | 180-240 |
| PXC10060 | 100X60 | 32 | 190-250 |
| PXC7264 | 72X64 | 48 | 190-210 |
| PXC2565 | 25X65 | 132 | 40-45 |
| PXC3365 | 33X65 | 108 | 60-75 |
| PXC4565 | 45X65 | 84 | 110-120 |
| PXC6565 | 65X65 | 60 | 180-200 |
| PXC2580 | 25X80 | 100 | 100-120 |
| PXC3080 | 30X80 | 80 | 110-130 |
| PXC3580 | 35X80 | 72 | 120-140 |
| PXC4080 | 40X80 | 56 | 120-135 |
| PXC4580 | 45X80 | 56 | 130-140 |
| PXC5080 | 50X80 | 48 | 150-190 |
| PXC5580 | 55X80 | 48 | 150-190 |
| PXC6080 | 60X80 | 40 | 180-210 |
| PXC8080 | 80X80 | 32 | 240-290 |
| PXC10080 | 100X80 | 24 | 260-350 |
| PXC12080 | 120X80 | 20 | 260-350 |
| PXC14080 | 140X80 | 16 | 300-400 |
| PXC33100 | 33X100 | 72 | 110-160 |
| PXC40100 | 40X100 | 56 | 130-170 |
| PXC48100 | 48X100 | 48 | 220-250 |
| PXC50100 | 50X100 | 40 | 220-250 |
| PXC60100 | 60X100 | 40 | 240-290 |
| PXC70100 | 70X100 | 32 | 250-350 |
| PXC80100 | 80X100 | 32 | 260-350 |
| PXC100100 | 100X100 | 24 | 300-400 |
| PXC120100 | 120X100 | 16 | 330-430 |
| PXC160100 | 160X100 | 12 | 360-460 |
| PXC100150 | 100X150 | 12 | 350-450 |
