EASCO UL Wire Duct, Cable Trunking
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | EASCO Wiring Duct | Place of Origin | China | |
| Model Number | EAR |
Product Description
|
Desp: plastic slotted cable trunk, wide slot cable duct |
| Material: Lead-Free PVC Material. Self-extinguishing.UL94 V-0 |
|
Length: 2 Meter (~78") |
|
Part No.: EAR |
FEATURES:
1)Aesthetics Lead Free Wiring Duct.
2)Available with round wide slot varying from 4mm to 8mm.
3)Easy insertion and removal of wire and cable.
4)Smooth edges can protect your hands & wiring insulation free from burrs or
sharp edges without abrasion
5)With mounting holes for easy mounting.
6)Non-slip cover prevent slipping of the cover.
7)Flush cover design holds more wires than traditional duct.
SPECIFICATION:
| Part No. | WxH | M/PACK | 14AWG/PCS |
| EAR1525 | 15X25 | 300 | 5-12 |
| EAR2025 | 20X25 | 232 | 5-12 |
| EAR2525 | 25X25 | 180 | 10-25 |
| EAR2030 | 20X30 | 192 | 15-25 |
| EAR2530 | 25X30 | 144 | 15-25 |
| EAR3030 | 30X30 | 120 | 15-25 |
| EAR3530 | 35X30 | 112 | 25-30 |
| EAR4030 | 40X30 | 100 | 25-35 |
| EAR3333 | 33X33 | 124 | 20-30 |
| EAR2535 | 25X35 | 144 | 15-25 |
| EAR3535 | 35X35 | 120 | 40-45 |
| EAR5035 | 50X35 | 100 | 55-65 |
| EAR2540 | 25X40 | 124 | 20-25 |
| EAR4040 | 40X40 | 80 | 60-70 |
| EAR6040 | 60X40 | 80 | 100-115 |
| EAR2545 | 25X45 | 128 | 20-25 |
| EAR3345 |
33X45 |
84 | 40-55 |
| EAR4545 | 45X45 | 92 | 60-70 |
| EAR6545 | 65X45 | 72 | 80-90 |
| EAR2550 | 25X50 | 100 | 20-25 |
| EAR3050 | 30X50 | 120 | 30-35 |
| EAR3550 | 35X50 | 120 | 40-45 |
| EAR4050 | 40X50 | 100 | 50-60 |
| EAR4550 | 45X50 | 80 | 60-70 |
| EAR5050 | 50X50 | 80 | 80-90 |
| EAR5550 | 55X50 | 72 | 80-90 |
| EAR6050 | 60X50 | 68 | 85-95 |
| EAR8050 | 80X50 | 52 | 150-170 |
| EAR10050 | 100X50 | 40 | 200-240 |
| EAR2560 | 25X60 | 132 | 40-45 |
| EAR3560 | 35X60 | 108 | 40-55 |
| EAR4060 | 40X60 | 96 | 100-115 |
| EAR4560 | 45X60 | 84 | 113-118 |
| EAR5560 | 55X60 | 72 | 115-130 |
| EAR6060 | 60X60 | 60 | 120-135 |
| EAR8060 | 80X60 | 44 | 180-240 |
| EAR10060 | 100X60 | 32 | 190-250 |
| EAR7264 | 72X64 | 48 | 190-210 |
| EAR2565 | 25X65 | 132 | 40-45 |
| EAR3365 | 33X65 | 108 | 60-75 |
| EAR4565 | 45X65 | 84 | 110-120 |
| EAR6565 | 65X65 | 60 | 180-200 |
| EAR2580 | 25X80 | 100 | 100-120 |
| EAR3080 | 30X80 | 80 | 110-130 |
| EAR3580 | 35X80 | 72 | 120-140 |
| EAR4080 | 40X80 | 56 | 120-135 |
| EAR4580 | 45X80 | 56 | 130-140 |
| EAR5080 | 50X80 | 48 | 150-190 |
| EAR5580 | 55X80 | 48 | 150-190 |
| EAR6080 | 60X80 | 40 | 180-210 |
| EAR8080 | 80X80 | 32 | 240-290 |
| EAR10080 | 100X80 | 24 | 260-350 |
| EAR12080 | 120X80 | 20 | 260-350 |
| EAR14080 | 140X80 | 16 | 300-400 |
| EAR33100 | 33X100 | 72 | 110-160 |
| EAR40100 | 40X100 | 56 | 130-170 |
| EAR48100 | 48X100 | 48 | 220-250 |
| EAR50100 | 50X100 | 40 | 220-250 |
| EAR60100 | 60X100 | 40 | 240-290 |
| EAR70100 | 70X100 | 32 | 250-350 |
| EAR80100 | 80X100 | 32 | 260-350 |
| EAR100100 | 100X100 | 24 | 300-400 |
| EAR120100 | 120X100 | 16 | 330-430 |
| EAR160100 | 160X100 | 12 | 360-460 |
| EAR100150 | 100X150 | 12 | 350-450 |
*Wire duct is supplied in lengths of 2m(~78"),complete with covers, in complete packages only.
*Special color, size, length upon request of reasonable quantity.
CERTIFICATES FOR WIRING DUCT.
UL:E354081 WIRE DUCT. CSA UL:E354081 WIRING TRUNKING. ROHS FOR HALOGEN FREE WIRING CABLE DUCT. ROHS: LEAD-FREE PVC CABLE DUCT. ROHS: FLEXIBLE WIRING DUCT. CE: SLOTTED WIRING CABLE TRAY.UV EXPOSURE TEST REPORT FOR WIRE DUCT. UL94V0:WIRE DUCT. TEMPERATURE TEST REPORT :CABLE TRUNKING SLOTTED. REACH :CABLE TRAY CABLE TRUNKING.REACH :CABLE CHANNEL.
