PET PC Membrane Keypad for SMD LED Resistors and Connectors
- T/T L/C D/P D/A
- 7 days
You May Like
-
Polyester Single Sided Pressure Sensitive Waterproof Switch Panel
-
Polyester Single Sided Waterproof Switch Panel
-
Polyester Pressure Sensitive Waterproof Switch Panel
-
Pressure Sensitive Waterproof Switch Panel Adhesiver Sticker
-
Carton Sealing Waterproof Switch Panel Adhesiver Sticker
-
Carton Sealing Rubber Membrane Key Switch
Product Details
| Place of Origin | China |
Product Description
Certification:ISO9001-2000 Certificate
Membrane switch keypad is made of PET, PC, rear adhesive is 3M467MP, 3M468MP, or ordinary adhesive, color is based on the Pantone
The membrane switch keypad with high quality and good service
Specifications:
Assembled with SMD LED, resistors and connectors
Components are guaranteed without any intermittent problem
In-house 100% functionally tested
Customized designs are welcome
Properties:
Operating voltage: < 35V DC
Operating current: < 100mA
Contact resistance: < 100 Ohms
Open circuit resistance: > 10M Ohms
Operating temperature: -35 to 70 degrees Celsius
Storage temperature: -45 to 90 degrees Celsius
Life expectancy: 500, 000 to 30, 000, 000 cycles
Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: 20 to 45g
Tactile ratio: FC > 40%
Operating humidity: up to 95% RH
Female, male connector, solder pins and heat seal connectors are available
