LEDSolution 16mm Curtain Outdoor SMD LED Panel

LEDSolution 16mm Curtain Outdoor SMD LED Panel thumbnail-1
LEDSolution 16mm Curtain Outdoor SMD LED Panel photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
LEDSolution
Place of Origin:
China
Model Number:
LS-OC-P16
Contact Supplier Request Quote Chat Now
Shenzhen LEDSolution Co.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LEDSolution
Place of Origin China
Model Number LS-OC-P16
Parameter Unit Value Pitch mm 16 Brightness nits 6,000 Color temperature deg. K 6,500 Viewing angle – Horizontal (50% brightness) deg. 120(-60~ +60) Viewing angle – Vertical (50% brightness) deg. 120(-60~ +60) Panel weight kg 5.5 Panel width mm 512 Panel height mm 768 Panel depth mm 120 Panel area sq. m. 0.393 Panel material Epoxy paint coated Aluminum Strip Operating temperature range deg. C -30 to +60 Humidity operating RH 10% ~ 90% International Protection IP IP65 Pixel type and configuration R/G/B 3in1 SMD Resolution per panel 32x48 Dot per panel 1,536 Dot per sq. meter 3,906 LED per sq. meter 3,906 Recommended minimum viewing distance m 14 Drive Mode Constant current drive Static Colors 16.7 millions Grey scale (linear) Levels 256 levels per color Brightness control Levels 100 Contrast ratio 1,000:1 Processing depth bit 12 Video frame rate Hertz 60 Display refresh rate Hertz 180 Input voltage (nominal) VAC 110 to 240 Input power frequency Hertz 50 to 60 Input power (max) Watts/ sq. m. 1,000 Input power (typical) Watts/ sq. m. 400 Lifetime (50% brightness) Hours ≥100,000 Red wavelength (dominant) nm 625 Green wavelength (dominant) nm 525 Blue wavelength (dominant) nm 470 Panel input format DVI Mounting System Hanging
