LEDSolution 12mm Permanent Outdoor Oval LED Panel

LEDSolution 12mm Permanent Outdoor Oval LED Panel thumbnail-1
LEDSolution 12mm Permanent Outdoor Oval LED Panel photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
LEDSolution
Place of Origin:
China
Model Number:
LS-O-P12
Contact Supplier Request Quote Chat Now
Shenzhen LEDSolution Co.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name LEDSolution
Place of Origin China
Model Number LS-O-P12
Parameter Unit Value Pitch mm 12 Brightness nits 6,000 Color temperature deg. K 6,500 Viewing angle - Horizontal (50% brightness) deg. 130 (+65/-65) Viewing angle - Vertical (50% brightness) deg. 60(+30/-30) Panel weight kg 26 Panel width mm 768 Panel height mm 576 Panel depth mm 170 Panel area sq. m. 0.442 Panel material Epoxy paint coated Cold rolled steel Ingress protection (front/rear) IP IP65/IP43 Operating temperature range deg. C -30 to +60 Humidity operating RH 10% ~ 90% Pixel type and configuration R/G/B 1,1,1 Resolution per panel 64 x 48 Dot per panel 3,072 Dot per sq. meter 6,944 LED per sq. meter 20,833 Recommended minimum viewing distance m 12 Recommended best viewing distance m 16~42 Colors 16 millions Grey scale (linear) Levels 256 levels per color Brightness control Levels 100 Contrast ratio 1,000:1 Processing depth bit 14 Video frame rate Hertz 60 Display refresh rate Hertz 600 Input voltage (nominal) VAC 110 to 240 Input power frequency Hertz 50 to 60 Input power (max) Watts / sq. m. 706 Input power (typical) Watts / sq. m. 283 Lifetime (50% brightness) Hours ≥100,000 Red wavelength (dominant) nm 620~625 Green wavelength (dominant) nm 520~525 Blue wavelength (dominant) nm 470~475 Panel input format DVI Data interconnection UTP Cat 5/Optical Fiber Mounting system Fixed with 4pcs M10 bolts
