Specifications
HIGH SPPED WITHOUT SHUTTLE NEEDLE LOOMuses the pulley device for yarn making more convenient to operate and more precise.
HIGH SPEED WITHOUT SHUTTLE NEEDLE LOOM JYZ8/30
Model |
JYZ8/30 |
JYZ6/50 |
JYZ4/80 |
JYZ2/110 |
JYZ2/130 |
JYZ2/160 |
Numbers Of Ribbon |
8 |
6 |
4 |
2 |
2 |
2 |
Width of Reed(mm) |
30 |
50 |
80 |
110 |
130 |
160 |
Weft Density |
3.5-36.7/cm |
|||||
Number Of Frame |
12-18 |
12-14 |
12-16 |
12-14 |
12-14 |
12-14 |
Cycle Pattern Chain |
48 |
48 |
48 |
48 |
48 |
48 |
Speed |
1300 |
1200 |
1000 |
900 |
800 |
700 |
Motor Power(KW) |
1.1 |
|||||
JYZ series high speed needle loom is used to weave various elasticity and non-elasticity light and medium tape, as bra tape, ribbon, shoulder tape etc all kinds of elastic tape and packing tape. It has the feature such as polish design, quick, high efficient. It also uses the pulley device for yarn which makes more convenient to operate and more precise for yarn.
STANDARD EQUIPMENT
CREEL 1SET
DEVICES ON REQUEST (SELECTIVE)
RIBBON COLLECTING DEVICE
PICKING-UP DEVICE FOR ELASTIC THREADS
SIZE AND WEIGHT OF MACHINE
NET WEIGHT/GROSS WEIGHT OF MACHINE 435kg/535kg
NET WEIGHT/GROSS WEIGHT OF CREEL 132kg/150kg
CRATE OF MACHINE 1400mm*960mm*1900mm
CRATE OF CREEL 2200mm*460mm*220mm
