HEAVY BELT LOOM

Specifications

endurable, noiseless, simple to operate, convenient to maintain etc.



HANGING RIBBON NARROW FABRIC LOOM JYS4/80

Model	JYS4/55
Numbers Of Ribbon	2
Width of Reed	55
Weft Density	3.5-36.7/mm
Number Of Frame	14
Cycle Pattem Chain	1:8 1:48
Bobbin	640
Speed(rpm)	900
Net/Gross	370kg/470kg
Crate of machine	1170mm*920mm*1900mm
Motor Power	1.5KW-6



JYS4/80	JYS2/110	JYS2/130
2	2	2
80	110	130
1.8-5/cm
8	8-12
cam shape1:8
800	640
800	750
800kg/531kg	435kg/535kg
1400mm*1170mm*1900mm	1400mm*960mm*1900mm
1.1KW-8

JYS Series of gallus webbing loom, it is manufactured by our company, which is a kind of new style machine after improving many times. The feature: endurable, noiseless, simple to operate, convenient to maintain etc. thus it is the most ideal equipment to weave the hanging ribbon of container bag, enclosure ribbon, buckle ribbon, towstrap, upper air safety belts and so on.

STANDARD EQUIPMENT

TENSION RACK 1SET

CREEL FOR 1SET

DEVICES ON REQUEST (SELECTIVE)

RIBBON COLLECTING DEVICE 1SET

SIZE AND WEIGHT OF MACHINE

NET WEIGHT/GROSS WEIGHT OF TENSION RACK   112kg/125kg

NET WEIGHT/GROSS WEIGHT OF CREEL 240kg/265kg

CRATE OF TENSION RACK 2200mm*440mm*210mm

CRATE OF CREEL 2650mm*540mm*460mm
