Specifications
Dual stream encoding (H.264/MJPEG)1/2.5-inch 2.0 Megapixel Aptina AR0330 CMOS, include 3.6mm fixed lens
IR view distance:20m
1) Dual stream encoding (H.264/MJPEG)
2) 1/2.5-inch 2.0 Megapixel Aptina AR0330 CMOS, include 3.6mm fixed lens
3)IR view distance: 20m(36pcs leds)
3) Main Flow: 2MP:1920*1080@15FPS 1MP:1280*720@30FPS
Minor Flow: 640*360@30fps
4) Support Multi-Screen software and CMS
5) Support Protocol: TCP, UDP, IP, HTTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPSec UpnP, RTP, and RTCP
Image Processing: Auto Exposure (AE); Auto White Balance (AWB); Auto Gain Control (AGC). Alarm action;support email message etc.
Device | ||
Model | IPS-Eye03L | IPS-Eye03S |
Device Type | 1.0 Megapixel CMOS Sensor | 2.0 Megapixel CMOS sensor |
Size | 1/4” | 1/2.5” |
Day&Night | Yes | |
Color | 3-8lux(IR ON) | |
IR Cut | Support | |
Filter | IR-CUT Filter | |
IR Led | Yes | |
IR Distance | 8-15M | |
Lens | ||
Lens | 3.6MM | |
IRIS | Fixed Aperture F1.2 | |
Viewing Angle | Horizontal 65° | |
Video | ||
Compression | H.264 | |
Resolution & Frame | Main Flow: 1280*720@30fps Minor Flow: 640*360@30fps | Main Flow: 1920*1080 @15fps 1280*720@30fps Minor Flow: 640*360@30fps |
Code Stream | Support Dual Stream | |
Code Rate | 32-4096kbps | |
Bit Rate Type | CBR & VBR | |
SNR | Above 50DB | |
Image Enhancement | Automatic White Balance, Backlight Compensation,Luminance, Contrast, Color Adjustment | |
Video Cover | 4 Region can be set up | |
Superposition of Words | User Defined | |
Flip Config | Up/Down, Left-right-flip | |
Alarm | ||
Audio | NO | |
Device |
| |
Audio In/ Out | 1 CH | |
Audio Compression | G.711/G.726 | |
Alarm In/ Out | 1CH | |
Alarm Way | Motion Detection | |
Alarm Procession | The central control monitor, Got to PTZ preset pos, Send E-mail, Log Record, SD Card storage, etc. | |
Protocol & Service | TCP,UDP,IP,HTTP,SMTP,DHCP,DNS,DDNS,ARP,ICMP,SMTP,POP3,NTP,RTP, RTCP,Pelco-D | |
Ethernet Port | Ethernet (10/100 Base-T),RJ-45 connector | |
Security | IP Address Filter,User Password Protection, User Access Log | |
Software | ||
WEB Browser | Microsoft Internet Explorer 6.0 or above,google,firefox, etc | |
Software Management | Multi-channel Network Surveillance System ONVIF Compatibility | |
Intelligent Software Function | Motion Detect,Miss Object Detection,Suspicious Detection, Moving Object Tracking, Guard Line Detection, etc. | |
Event Action | Video Capture Saved to Backing Device, Send Email, Send SMS, Zoom in alarm, Pop ap map, Go to PTZ preset pos etc | |
Mobile Client | Iphone, Android | |
Remote Access | DDNS, software, P2P | |
General | ||
Accessories | Power adapter, Network Cable, Stand, User Manual, Disk, Screw Bag | |
Power Consumption | DC 12V/1A | |
Operation Temperature | -10°C——60°C | |
Operation Humidity | 10%-80% | |
Weight | 0.415KG | |
Dimensions | Φ69*189mm (Dia*L) | |
Certification | CE,FCC | |
