1080P P2P Low Lux Video Push AP TF Slot Support IP Camera

1080P P2P Low Lux Video Push AP TF Slot Support IP Camera thumbnail-1
1080P P2P Low Lux Video Push AP TF Slot Support IP Camera photo-1
US$ 60 - 65 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CP
Model Number:
IPS-Eye06S
Contact Supplier Request Quote Chat Now
Shenzhen Capital Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenZhen or hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CP
Model Number IPS-Eye06S
Type Digital Camera
Style Dome Camera
Sensor Other, Low Lux
Technology Pan / Tilt / Zoom
Special Features Other

Specifications

1) Dual stream encoding (H.264/MJPEG)
2) 1/2.5-inch 2.0 Megapixel Aptina AR0330 CMOS, include 3.6mm fixed lens

1) Dual stream encoding (H.264/MJPEG)
2) 1/2.5-inch 2.0 Megapixel Aptina AR0330 CMOS, include 3.6mm fixed lens
3)IR view distance: 20m(36pcs leds)
3) Main Flow: 2MP:1920*1080@15FPS 1MP:1280*720@30FPS
Minor Flow: 640*360@30fps
4) Support Multi-Screen software and CMS
5) Support Protocol: TCP, UDP, IP, HTTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPSec UpnP, RTP, and RTCP
Image Processing: Auto Exposure (AE); Auto White Balance (AWB); Auto Gain Control (AGC). Alarm action;support email message etc.





Device

Model

IPS-Eye06L

IPS-Eye06S

Device Type

1.0 Megapixel CMOS Sensor

2.0 Megapixel CMOS sensor

Size

1/4”

1/2.5”

Day&Night

Yes

Color

3-8lux(IR ON)

IR Cut

Support

Filter

IR-CUT Filter

IR Led

Yes

IR Distance

8-15M

Lens

Lens

3.6MM

IRIS

Fixed Aperture F1.2

Viewing Angle

Horizontal 65°

Video

Compression

H.264

Resolution & Frame

Main Flow: 1280*720@30fps

  Minor Flow: 640*360@30fps

 Main Flow: 1920*1080 @15fps   1280*720@30fps Minor Flow: 640*360@30fps

Code Stream

Support Dual Stream

Code Rate

32-4096kbps

  Bit Rate Type

CBR & VBR

SNR

Above 50DB

Image Enhancement

Automatic White Balance, Backlight Compensation,Luminance, Contrast, Color Adjustment

Video Cover

4 Region can be set up

Superposition of Words

User Defined

Flip Config

Up/Down, Left-right-flip

Alarm

Audio

NO

Device



Audio In/ Out

1 CH

Audio Compression

G.711/G.726

Alarm In/ Out

1CH

Alarm Way

Motion Detection

Alarm Procession

The central control monitor, Got to PTZ preset pos, Send E-mail, Log Record, SD Card storage, etc.





Protocol & Service

TCP,UDP,IP,HTTP,SMTP,DHCP,DNS,DDNS,ARP,ICMP,SMTP,POP3,NTP,RTP, RTCP,Pelco-D

Ethernet Port

Ethernet (10/100 Base-T),RJ-45 connector

Security

IP Address Filter,User Password Protection,  User Access Log

Software

WEB Browser

Microsoft Internet Explorer 6.0 or above,google,firefox, etc

Software Management

Multi-channel Network Surveillance System ONVIF Compatibility

Intelligent Software Function

Motion Detect,Miss Object Detection,Suspicious Detection, Moving Object Tracking, Guard Line Detection, etc.

Event Action

Video Capture Saved to Backing Device, Send Email, Send SMS, Zoom in alarm, Pop ap map, Go to PTZ preset pos etc

Mobile Client

 Iphone, Android

Remote Access

 DDNS, software, P2P

General

Accessories

Power adapter, Network Cable, Stand, User Manual, Disk, Screw Bag

Power Consumption

DC 12V/1A

Operation Temperature

-10°C——60°C

Operation Humidity

10%-80%

Weight

0.415KG

Dimensions

Φ57*11.3mm (Dia*L)

Certification

            CE,FCC
