H.264 1/4-inch 1.0 MP CMOS Plug & Play IP Camera

H.264 1/4-inch 1.0 MP CMOS Plug & Play IP Camera thumbnail-1
H.264 1/4-inch 1.0 MP CMOS Plug & Play IP Camera photo-1
US$ 35 - 40 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Type:
Digital Camera
Style:
Mini Camera
Contact Supplier Request Quote Chat Now
Shenzhen Capital Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen or hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Type Digital Camera
Style Mini Camera
Sensor CMOS
Technology Pan / Tilt / Zoom
Special Features Other, household

Specifications

1) Dual stream encoding (H.264/MJPEG)
2) 1/4-inch 1.0 Megapixel OV9712 CMOS, include 2.8mm fixed lens
3)IR view distance: 15m

1) Dual stream encoding (H.264/MJPEG)
2) 1/4-inch 1.0 Megapixel OV9712 CMOS, include 2.8mm fixed lens
3)IR view distance: 15m(22pcs leds)
4) Main Flow: 1280*720@30fps Minor Flow: 640*360@30fps
5) Support Multi-Screen software and CMS
6) Support Protocol: TCP, UDP, IP, HTTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPSec UpnP, RTP, and RTCP
Image Processing:Auto Exposure (AE); Auto White Balance (AWB); Auto Gain Control (AGC). Alarm action;support email message etc.



Model



IPS-Eye07L



Item

Household IP Camera



Device Type

1.0 Megapixel CMOS sensor



Size

1/4



Day and Night

YES



Min.Scene  Illumination

3-8lux(IR ON)



Infrared sensitivity

Support



Filter

IR-CUT



IR-led

YES



IR distance

15M

LENS







Lens

2.8 MM



Focus

Fixed Lens



Aperture

Fixed Aperture

Video







Compression

H.264



  Picture Resolution

Main Flow:   1280*720@30fps

Minor Flow:   640*360@30fps



Flow Type

Dual Stream encoding



Bit Rate

128-8192kbps



Bit Rate Type

CBR/VBR



S/N Ratio

>50DB



Image enhancement

Auto White Balance,Backlight compensation,Brightness,Contrast,Saturation adjusted



Subtitles input

Support channel name, date/time



Flip Config

Up/down, Left/right

Audio/ Alarm







Audio

Two way audio



equipment

Built-in MIC,horn



  Audio input/output



one channel audio input, one channel audio output





Audio  Compression

G.711



Alarm way

Motion Detection:Configure motion detection area,detecting sensitivity is adjustable

Cover alarm:The alarm sensitivity is adjustable



Alarm processing

The control center to monitor,Go to PTZ preset pos,Send E-mail, Log record,SD card storage etc.

Network







Protocal

TCP,UDP,IP,HTTP,SMTP,DHCP,DNS,DDNS,ARP,ICMP,SMTP,POP3,NTP,RTP, RTCP,Pelco-D



Ethernet

Ethernet (10/100 Base-T),RJ-45 connector



Safety

IP address filtering,User level password protection,The user access log

Software







WEB Browser

Microsoft Internet Explorer 6.0 and above,google,firefox etc.



Software Management

CMS and the devices Compatible with ONVIF



Software intelligence function

Motion detection,Miss object detection, Moving object tracking, counting, Retrograde motion detection, etc.



Event action

Files are stored to the back end equipment,Send E-mail,Send SMS,Zoom in alarm,Pop ap map ,Go to PTZ preset pos etc



Mobile Phone

Support iPhone,Android



Remote Access

DDNS,Software,P2P

Physical properties







Accessories

Power adapter, Network cable, Stand, Operation manual, CD, Screw bag



Power Comsumption

DC 5V/2A



Temperature

-10°C——60°C



Humidity

10%-80%



  Weight

KG



Dimension

mm L*W*H



Certification

CE,FCC
