H.264 720P -1440P Wireless Waterproof IR-CUT IP Camera

H.264 720P -1440P Wireless Waterproof IR-CUT IP Camera thumbnail-1
H.264 720P -1440P Wireless Waterproof IR-CUT IP Camera photo-1
US$ 51.6 - 95 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CP
Sensor:
CMOS
Contact Supplier Request Quote Chat Now
Shenzhen Capital Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen or hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CP
Sensor CMOS
Technology Pan / Tilt / Zoom
Special Features Waterproof / Weatherproof

Specifications

1) Dual stream encoding / H.264 compression mode
2) 1/4-inch OV 9712 1.0 Megapixel CMOS
3) resolution:1280*720@30fps

1) Dual stream encoding / H.264 compression mode
2) 1/4-inch OV 9712 1.0 Megapixel CMOS
3) resolution:1280*720@30fps







IP CAMERA



IPS-512V

IPS-612V

IPS-1012V

IPS-WDR2012V



IPS-WDR712V



Model







Item



Device Type

960P AR0130 CMOS

720P OV9712d CMOS sensor

1080P Sony MX122 CMOS sensor

960P

Aptina

9M034

CMOS

sensor

1440P

AR0331

CMOS

sensor



Size

1/3

1/4

1/2.5

1/3

1/3

Day and Night

Yes

Min.Scene  Illumination

0.01lux(IR ON)

0.5lux(IR ON)

0.01lux(IR ON)

0.005lux

(IR ON)

0.01lux

(IR ON)

Infrared sensitivity

Support

IR Filter

IR-CUT

IR-led lamp

36pcs

IR distance

30-50M

Electronic shutter

1/5-1/15,000 /S

Lens



lens

2.8-12MM

Focus

Manual zoom

Aperture

Fixed Aperture F1.2

Video



Compression

H.264 Main Profile

  Picture Resolution

1280*960@30ps   1280*720@30fps

1280*720@30fps

1920*1080@30fps

1280*960

@25fps

2560*1440@

25fps

Steam flow

Support dual stream

Bit Rate

128-8192kbps

Bit Rate Type

CBR/VBR

S/N Ratio

>50DB

Image enhancement

Auto White Balance,Backlight compensation,Brightness,Contrast,Saturation adjusted

Subtitles input

Support channel name, date/time

Flip Config

Up/down, Left/right

Audio/ Alarm







Audio

Support the microphone input andAudio output, support two-way voice intercom equipment

equipment

An external audio equipment

Audio input/ output

one channel audio input, one channel audio output

Audio  Compression

G.711/G.726

Alarm input/output

  No

Alarm way

Motion Detection:Configure motion detection area,detecting sensitivity is adjustable

Alarm processing

The control center to monitor,Go to PTZ preset pos,Send E-mail, Log record,SD card storage etc.

Network







Protocal

HTTP,TCP/IP,UDP,SMTP,DDNS,DNS,SNTP,DHCP,FTP,RTP,RTSP,UPNP,ONVIF,28181

Ethernet

Ethernet (10/100 Base-T),RJ-45 connector

Safety

IP address filtering,User level password protection,The user access log

Software







WEB Browser

       Microsoft Internet Explorer 6.0 and above,google,firefox etc.

Mobile Phone

Support iPhone,Android,Bit rate:32K – 512K adjustable,Frame rate:6–12 fps

Software Management

CMS and the devices Compatible with ONVIF

Software intelligence function

Motion detection,Miss object detection, Moving object tracking, counting, Retrograde motion detection, etc.

Event action

Files are stored to the back end equipment,Send E-mail,Zoom in alarm,Go to PTZ preset pos etc

Remote Access

DDNS,Software,P2P

Physical properties







Accessories

Power adapter, CD, Screw bag

Power Comsumption

           DC 12V ,Module power consumption is less than 2 W

Temperature

-20°~60°C

Humidity

-10~85%

Weight







Dimension







Certification

CE ,FCC
