GD-261-1 Pensky-Martens Closed-Cup Flash Point Tester

GD-261-1 Pensky-Martens Closed-Cup Flash Point Tester thumbnail-1
GD-261-1 Pensky-Martens Closed-Cup Flash Point Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-261-1
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-261-1

Introduction:

This instrument is designed and manufactured as per standards GB/T 261-2008 Determination of Flash Point - Pensky-Martens closed cup method and ASTM D93 Standard Test Methods for Flash Point by Pensky-Martens Closed Cup Tester. It is used to make determination of the closed cup flash point of the petroleum products.


Features:

1.         Single chip micr℃omputer control technique.LCD screen displays.English man-machine interaction interface.The heating power is continuously step-less adjustable.The rate of heating up is exact.Easy setting for parameters.

2.         The LCD screen has prompting menu,prompting input operation interface.It shows the setted parameters, real-time temperatures and other test parameters.Press the “record”button when the flash point appears.The screen will show and reserve the flash point.

3.         The structure is newly design and small.Stainless steel table-board looks clean and beautiful.It can be used as long as equipped with gas or other civilian fuels.It is easy to use and test results exact.


Specifications:

Power supply AC( 220±10% )V, 50Hz
Heating device
　		 (1)The furnace is silicon carbide material. Power is 600W
(2)The heating power is adjustable from 0 W to 600W
Heating rate Procedure A: (5~6)℃/min, Procedure B:(1~1.6)℃/min
Automatically controlled
Stirring device (1)Stirring motor: BYGH101 stepping motor
(2)Driving mode: flexible shaft
(3)Shaft size: 8mm*40mm
Stirring rate Procedure A: (90~120)RPM, Procedure B: (250±10)RPM
Igniting device (1)Igniting source: gas (or other civilian fuels, the same below)
(2)Electric ignition. Gas flame diameter:3.2mm~4.8mm
Temperature testing probe RTD, PT100
Ambient temperature ≤ 35℃
Relative humidity ≤ 85％
Maximum power consumption 650W


Product Tags: Flash point tester , Open a flash point tester , Pensky-Martens Flash Point Tester
