Specifications
Stone&Metal Processing CNC Router ,high speed driver,water cooling syetem ensuing long life of the cutter..more| Model | XJ1218 |
| Working Area | 1,200×1,800×100mm |
| Spindle Motor | 2.2 kw inverter-driven water-cooled spindle motor or HSD Italian Air-cooled spindle motor |
| working mode | Stepper motor |
| control system | DSP(128MB) or PCIMC control system |
| Drive mechanism | German imported ballscrew, round orbit for x,y,z axis Option: Square Linear Rail for X,Y,Z Axis |
| table surface | T-slot extrusions |
| frame | solid cast-iron cast working table, solid aluminum gantry support |
| motion positioning accuracy | ± 0.02/300mm |
| Repositioning accuracy | ± 0.01mm |
| Max motion Speed | 25,000mm/min |
| Max engraving speed | 9000mm/min |
| Rotating Speed of Spindle | 2,4000rpm |
| Engraving Tools | 3.175mm, 4mm 6.00mm |
| Dictate Formate | G code, *.u00, *.mmg, *.plt/HPGL/NC |
| Operating voltage | AC220/50Hz |
| soft ware | Type3 original with dongle or Wentai , ArtCAM software//ARTCAM/CAXA |
| Packing size | 1900x 2050x 1500mm |
| Net weight | 402kg |
| Gross weight | 460kg |
| noise level | LAeep dB(A)72±1 |
| LAeep dB(A)80±2 | |
| LAeep dB(C)95 | |
| Optional parts | Dust Collecting System |
| Rotary Device | |
| Mist Sprayer | |
| Flume | |
| DSP System w/Portable Control Pad128MB |
Application:
This machine is applicable to :aluminium board cutting,aluminium plastic board,aluminium honeycomb board,aluminium profiled bar,3D carve artwork,wave board production,man-made profiled bar,LED,neon light slot character cutting,light-trank model procession,acrylic,cooper board,PVC board,man-made stone,MDF board.
Features and specialties:
1.Two-nut rolling ball screw of high precision made in Germany makes the aperture to the minimum when it is working.
2.Imported four-row steel ball linear rail makes a balance pressure and insures the mechanical precision and high intensity.
3.Restoring function enable th emachine continue to work even stop suddenly.
4 Special memory for different cutting spots.
5.The lathe table is firm and durable,not disformed easily in long time,makes orientation more precise.
6.The engraving precision is high when making billboard,and the engraving is flat and clearly,even cutting thickness is up to 20mm.
7.Groove steel lathe bed or foundry bed is optional.
