Specifications
multi-spindle wood 3d cnc router1.time-saving woodworking
2.vacuum table
3.imported linear way Hiwin
4.rack and gear
multi-spindle 3d cnc wood router
proper features:
1) Integral cast-iron lathe bed, firm and non-deforming ,high rigidity and high accuracy,good performance and durability.
2) Unique multi-spindle design, quantity of machine heads and power of spindle can be choosed according to the customers requirements. The distance between spindles can be freely adjusted according to the workpiece deing processed.
3) The machine can complete the workload of several machines at the same time, saving production time and cost, enhancing the working efficiency.
Applicable material:
natural granite, crystalline stone, marble, jade, blue stone and various manmade stone type, glass type, copper, iron, plastic and wooden materials of stone and metal processing industries
technical parameters:
Model | XJ-1325 | |
Working Area | 1,300×2500×200mm | |
Spindle Motor | 2.2KW *4 Inverter-driven spindle motor cooled by water (or air for option) | |
Working Mode | Stepper motor | |
Control System | DSP(128MB) or PCIMC control system | |
Drive Mechanism | German imported ballscrew for x,y,z axis | |
Table Surface | T-slot extrusions | |
Frame | Cast wholely by Iron | |
Motion Positioning Accuracy | ±0.02/300mm | |
Repositioning Accuracy | ±0.01mm | |
Max Motion Speed | 12,000mm/min | |
Max Engraving Speed | 9,000mm/min | |
Rotating Speed of Spindle | 2,4000rpm | |
Engraving Tools | 3.175mm, 4mm 6.00mm | |
Dictate Formate | G code, *.u00, *.mmg, *.plt/HPGL/NC | |
Operating Voltage | AC220/50Hz | |
Software | Type3 original with Dongle or Wentai , ARTCAM/CAXA | |
Packing Size | 1850×1710×1400mm | |
Net Weight | 370kg | |
Gross Weight | 420kg | |
Noise Level | Racing | LAeep dB(A)72±1 |
Engraving | LAeep dB(A)80±2 | |
Engraving Peak | LAeep dB(C)95 | |
Optional Parts | Dust Collecting System | |
| ||
Rotary Device | ||
Mist Sprayer & Flume | ||
DSP System w/Portable Control Pad (128MB) | ||
Guarantee & Aftersales Service:
Guarantee for one year
24-hour technical support by email or calling
User-friendly English manual for machine using and maintaining
