Specifications
advertising cnc router1 Break point memory for 10 pcs
2 German imported bearing screw
3 Stepper motor
4 CE certificate
1.Features& spcialities
1. Integrated optimized design and high quality aluminum alloy frame, which ensure solid and warp-proof
2. unspace ball screw using Germany technology, aligning with high power driving motor and imported coupling, that make movement stable and work precise in a long time.
3. high power non-brushing motor, N-CVT, power saving, lower noise, strong cutting capability, which ensure a batch process for a long time.
4. Restoring function enable the machine stop running automatically while power off, and automatically restart to work when power on,and also can store the break point from which for later operation to start, with the function of anticipating working time, auto tool sensor, the rotating speed and processing depth could be adjusted optionally.
2.Application field
Sign board process, mould, bronzing mould, motor, trim injection mould, shoe mould, badge, pattern mould, art carve, dial, font mould, mold, sign and label etc.
Specifications:
Description | parameter | |
XYZ working area | 1200*1200*100mm | |
Max motion Speed | 25,000mm/min | |
XYZ travel positioning accuracy | ±0.05mm | |
XYZ repositioning positioning accuracy | ±0.05mm | |
Gantry | cast-aluminium | |
lathe structure | casting iron | |
drive system X-Y axis | Ball screw | |
drive system Z axis | Ball screw | |
Spindle power | 1.5KW | |
Max velocity | 8m/min | |
Max working speed | 6m/min | |
Spindle speed | 0-24000rmp | |
work mode | Stepper | |
Working voltage | AC220V | |
Command language | G code | |
Interface | USB | |
Operating system | Ncstudio(weihong) | |
Flash memory | 128 | |
X-Y resolution | 0.025mm | |
Software environment | Wentai type3 artcam | |
Running environment | Temperature:0-45°C | |
Packing size | 1800 x 1800 x 1400mm | |
Net weight | 370kg | |
Gross weight | 420kg | |
Main Package content | ||
1 | English Manual x 1 | |
2 | Power Lead x 1 | |
3 | USB Lead x 1 | |
4 | Water Pump x 1 | |
5 | Water Tank x 1 | |
6 | Tools box x 1 | |
