Laser Engraving Machine(CE)

Name: Laser Engraving Machine(CE)
Brand: XYZ-TECH
SKU: 144438732
Availability: InStock

Jinan XYZ-Tech CNC Equipment Co., Ltd.

US$ 100 - 8,000 MOQ: 1 Set

Key Specifications

Laser Type:

CO2

Place of Origin:

Shandong, China

Brand Name:

XYZ-TECH

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Laser Type CO2

Place of Origin Shandong, China

Brand Name XYZ-TECH

Model Number 1280

Specifications

Laser Engraving Machine(CE) has compact and professional design,high practicability,support offline working,etc....

Laser engraving Machine

Machine Description	XJ-1280 Laser Engraving and Cutting Machine
Machine Performance:
Laser-type	Hermetic and detached CO2 laser tube
Laser-power	80W (100W ,130w for option)
Cooling Mode	Circulating-water-cooling
Power Adjustment	0-100% controlling, no segment and adjusting by software
Machine Control and Drive	Speedy DSP controlling, stepper motor
Max Engraving Speed	1200mm/s
Max Cutting Speed	500mm/s
Repeating Location	±0.01mm
Minimum Character	Chinese character 1.5mm, crisscross-row 1mm
Max Power	750W
Adjustable Up-down Distance of Laser Head	20mm
Working Travel Area	1200×800mm, 800mm width with infinity material-feeding
Table Area	1250×850mm
Up-down Range of Working Table	Mechanical 400mm
Working Voltage	AC220V 50Hz
Working Environment	Temperature: 0-45, Humidity: 5%-95%, and congeal-water removed
Controlling Software Language	English, Simplified Chinese, Traditional Chinese and procuring of multi-languages
Dictate Format	.plt,.dst,.dxf,.bmp,.dwg,.al,*las, Support AutoCAD,CoreDraw direct outputting


Packaging Dimension (L×W×H)	190013001200mm
Packaging	Wooden box
Gross Weight	357kg
Machine Color	Customizable
Delivery Time	15 days
Payment	T/T

Optional Equipment	Rotary attachment
	Motorized up-down table
	Water-cooling unit
	Red-light position
	Vacuum table
	DSP Off-line operation with usb flash

proper features

compact and professional design,high practicability.
DSP control system,adopting stepper motor and high qulity drive,ensure high speed and wonderful accuracy.
USB interface can support data transittimg to be quickly finished.
Liquid crystal display panel.
Transmit files directly from Coredraw,AutoCAD,high speed USB 2.0 interface output can support off-line working..
Working resume from power break point when power on .
Electrical drive up-down table ,rotary device,red dot ,vacuum,etc.are for option.
Application:art gift,advertisement decoration,building upholster,paper product and other industries.

Guarantee & Aftersales Service:

Laser tube 2400 hours' working time

Comprehensive guarantee for half year

24-hour technical support by email or calling

User-friendly English manual for machine using and maintaining
