Specifications
XJ1325 cnc plasma manual sheet metal cutting machine1)working range1300*2500mm
2)working type:no touching
3)cnc cutter
4CE
XJ1325 cnc plasma manual sheet metal cutting machine
1. technical parameters
Plasma cutter cnc XJ1325 | |||
Items | Parameters | ||
Working area(mm) | X | 1300 | |
Y | 2500 | ||
Transmission system | X | Belt | |
Y | Belt | ||
Z | Ballscrew | ||
Lead rail system | X | Linear guide rail | |
Y | Linear guide rail | ||
Z | Linear guide rail | ||
Plasma | Power | 8.5 kw | |
Plasma Current | 60A / 100A | ||
Cooling Type | Water-cooling | ||
Origin | China | ||
About drive systems | X | stepper | |
Y | stepper | ||
Z | stepper | ||
Stepper motor and driver | Made in China | ||
Air compressor | option | ||
Machine body |
| ||
Software environmant | Windows 98/2000/XP | ||
Control System | DSP (USB) /Ncstudio control system | ||
Compatible file formats | G code ; *.u00 ; *.mmg ; *.plt . | ||
Compatible CAD/CAM Softwares | Ucancam V8/Type3/ArtCam | ||
Working Voltage | AC380V 50Hz | ||
Table size | 1340*2680mm | ||
Cutting speed | 8.0m/min | ||
Interface type | USB | ||
Processing materials | iron plate, aluminum plate, galvanized sheet, White Steel plate, Titanium plates | ||
Cutting thickness of material | Depends on the materials | ||
Warranty guarantee | One-year after-sale services | ||
Model | XJ1325 |
Price (FOB Chinese Port) |
|
Working Area(X*Y) | 1300mm×2500mm |
Cutting thickness | according to the material and the power |
Work speed | 0-50000mm/min |
Cutting Speed | 0-8000mm/min |
Cutting thickness | o.5-8mm |
|
|
Document Transmission Form | USB Interface |
Working Form | Untouched Arc Striking |
Working Voltage | 3-Phase 380V |
Power | 8.5KW-10.5KW |
G.W. | 980KGS |
|
|
3.Applications:
working materials: Iron Sheets, Aluminum sheets, Galvanized sheets, Titanium Plates.
4Provide service
1 to provide you with one year product warranty
2 to provide you with technical support, you can e-mail contact us, to ensure timely for you to solve the problem
5.SAMPLE
