XYZ-TECH Professional Paper Cutting Machine (CE)

Specifications

paper cutting plotter
1 advanced subdivision circuit with low noise
2 Emergency stop,free setting original point
3 CE/ISO

XYZ-TECH Professional Paper Cutting  Machine (CE)

(Key parts of the Plotter each for one will be externally given with the machine)

1. Feature:

1) Forward direction and reverse direction paper feed;

2) Emergency stop and free setting original point;

3) Maximum speed of 375mm/s;

4) Cutter speed and cutter pressure memory and storage

5) Double photoelectric reset without any collision;

6) Perfect output and without any saw tooth at high speed

7) Using the most advance subdivision circuit and having low noise

8) Using switching power supply and its operation that isn’t influenced by voltage change

9) Circuit uses low power consumption and doesn’t need fan for heat radiation so as to ensure long time and reliable operation

2. Technical specification:

Model	XJ-720	XJ-860	XJ-960	XJ-1160	XJ-1360	XJ-1660
Paper Feed Width	720mm	850mm	950mm	1130mm	1330mm	1660mm
Real Cutting Range	630mm	720mm	800mm	1000mm	1200mm	1500mm
Cutting Speed	0~500mm/s	0~375mm/s
Cutter Pressure	0~400g
Language Form	HP-GL / DMPL compatible
Power Supply	Voltage-stabilized source
Buffer	4M
Stand	not have	Existence
Liquid Crystal Screen	not have	Existence, English version
Accessory	software 1pc, cutters 3pcs, collet 1pc, s tand 1pc, pen collet 1pc, data cable 1pc, power supply cable 1pc, manual 1pc, guarantee card 1pc

3. Applicable fields:

applicable to carve graphics on instant stick, reflective film, transfer printing paper, gush arenaceous film and other double-sided materials , also can be  drawing equipment in garment industry.

4. Guarantee&Aftersales service

a.  guarantee for one year

b.  24 hour technical support by email or calling

c.  User-friendly english manual for machine using and maintaining
