Specifications
mini cnc milling router machine*Block cast fuselage
*CE certificate.
*DSP control system.
*USB interface
XJ6090 mini cnc milling router machine
Specifications:
| Model | XJ-6090 | |
| Working Area | 600×900×80mm | |
| Spindle Motor | 1.5KW Air-cooled spindle | |
| Working Mode | Stepper motor | |
| Control System | DSP(128MB) or PCIMC control system | |
| Drive Mechanism | German imported ballscrew for x,y,z axis | |
| Table Surface | T-slot extrusions | |
| Frame | Cast aluminum | |
| Motion Positioning Accuracy | ± 0.02/300mm | |
| Repositioning Accuracy | ± 0.01mm | |
| Max Motion Speed | 8,000mm/min | |
| Max Engraving Speed | 5,000mm/min | |
| Rotating Speed of Spindle | 2,4000rpm | |
| Engraving Tools | 3.175mm, 4mm 6.00mm | |
| Dictate Formate | G code, *.u00, *.mmg, *.plt/HPGL/NC | |
| Operating Voltage | AC220/50Hz | |
| Software | Type3 original with Dongle or Wentai , ArtCAM software/ARTCAM/CAXA | |
| Packing Size | 1500×1170×1300mm | |
| Net Weight | 161kg | |
| Gross Weight | 205kg | |
| Noise Level | Racing | LAeep dB(A)72±1 |
| Engraving | LAeep dB(A)80±2 | |
| Engraving Peak | LAeep dB(C)95 | |
| Optional Parts | Dust Collecting System | |
| Rotary Device | ||
| Mist Sprayer | ||
| Flume | ||
| DSP System w/Portable Control Pad (128MB) | ||
Features:
1) Lathe bed is cast wholly and firmly and will not deform;
2) Imported ball screw rod and round guide rail to ensure accuracy ;
3) Subdivision stepper motor with excellent performance, quick speed, stable operation, and large cutting movement to ensure long and safe operation ;
4) Frequency conversion water-cooling large power motor, low noise, even speed ;
5) Humanistic design, the machine can be disassembled, so it is easily transported ;
6) Applicable to: a) Chest species b) Tablet species c) Building models d) Signs e) Metal f) Wooden models g) Embossed pictures.
Guarantee and after-sale service:
1)1 year guarantee
2)24 hours technical support by e-mail or calling
3) User-friendly english manual and Video CD for machine using and maintaining
