Japan graphtec ce6000040cm / 60cm / 120cm cutting plotter
brand: Graphtec
size: 40cm,60cm,120cm
cut thick: 0.25mm
function: vinyl cutting plotter
weight:40Kg for 120cm width
Compatible cutter type: Graphtec Supersteel blades, 0.9MM and 1.5mm diameter
Specifications:
| Item | CE6000-40 | CE6000-60 | CE6000-120 | CE6000-120-AMO |
| CPU | 32-bit CPU | |||
| Original Japan graphtec CE6000 cutting plotter | ||||
| Configuration | Grit rolling type, digital servo drive | |||
| Max. cutting area | 375 mm x 50 m *1 | 603 mm x 50 m *1 | 1213 mm x 50 m *1 | |
| (Guaranteed cutting area) | (356 mm x 2 m *1) | (584 mm x 5 m *1) | (1194 mm x 5 m *1) | |
| Mark scanning margin | Type 1 mark: Front 15 mm, Rear 35 mm, Left/Right 15 mm | |||
| Type 2 mark: Front 17 mm, Rear 37 mm, Left/Right 15 mm (Length of media up to 2 m) | ||||
| Number of push roller | 2 rollers | 2 rollers | 3 rollers | 4 rollers |
| Max. cutting speed | 600 mm/s (All directions) | 900 mm/s (at 45º direction) | 1000 mm/s (at 45º direction) | |
| Max. acceleration | 21.2 m/s2 (at 45º direction) | 13.9 m/s2 (at 45º direction) | ||
| Max. cutting force | 2.94 N (300 gf) in 31 steps | 4.41 N (450 gf) in 38 steps | 4.41 N (450 gf) in 38 steps | |
| (Instantaneous max. force) | (3.2 N (330 gf)) | (4.9 N (500 gf)) | (4.9 N (500 gf)) | |
| Minimum character size | Approx. 5 mm alphanumeric (varies depending on character font and type of media) | |||
| Repeatability | Max. 0.1 mm in plot up to 2 m *1 | |||
| Mountable number of tools | 1 tool | |||
| Blade type | Supersteel | |||
| Pen type | Oil-based ballpoint, Water-based fiber-tip pen | |||
| Media type | Self-adhesive marking film (vinyl, fluorescent, reflective) excluding high-intensity reflective film, up to 0.25 mm thickness | |||
| Polyester film, up to 0.25mm thickness (unguaranteed accuracy) | ||||
| Perforation cutting | Yes (performed by force control) | |||
| Interface | RS-232C / USB2.0 (Full Speed) | |||
| Buffer memory | 2 MB | |||
| Command sets | GP-GL / HP-GL™ emulation (Set by the menu or the command, and selects from GP-GL, HP-GL™, or Auto detect) | |||
| Display | Graphic type LCD with backlight (240dots x 128dots) | |||
| Registration mark sensing system | Scans the mark by optical sensor (ARMS5.0) | |||
| Power source | 100 to 120, 200 to 240 V AC (Auto switch), 50 / 60 Hz | |||
| Power consumption | 120 VA | |||
| Operating environment | 10 to 35 ºC, 35 to 75 % R.H. (non-condensing) | |||
| (Guaranteed accuracy) | (16 to 32 ºC, 35 to 70 % R.H. (non-condensing)) | |||
| External dimensions (W x D x H, Approx. [mm]) | 672 x 338 x 266 | 900 x 593 x 1046 | 1541 x 736 x 1250 | |
| Weight | 10.5 kg | 21 kg (including stand) | 40.5 kg (including stand) | |
| Included software *2 | Windows Driver, Graphtec Studio, Cutting Master 3, Plotter Controller | |||
| Compatible OS *2 | Windows 8 / 7 / Vista / XP, Mac OS 10.5.8 to 10.8 | |||
| Compatible Standards | Safety: cUL / CE mark, EMC: VCCI Class A / FCC Class A / EN55022 Class A | |||
Other details of graphtec cutting plotter:
Features:
1. Economical
2. user-friendly
3. Optimum
4. good cutting quality
5. Multi-usage: Advertising label. The control panel. Phone beauty. Mobile phone buttons. The serial number label. Clothing cutting such as thermal transfer; Heat transfer T-shirt. Souvenirs. Glass products, car stickers. Labeling. Any shape infra-red positioning, suitable for cutting
Application:
Billboard
Cutting film, Transparent or Semi-Transparent film, Reflective film, Fluorescent film etc.
Sticker & Label
Cutting Film, Making a sticker & Label, P.O.P etc.
Traffic Sign
High Intensity Reflective Sheet for making traffic sign etc
Making a Package
Card Board, E/F/G grade Corrugated board etc
High Functional Film
Flexible Print Circuits, Membrane switch sheet, PET Film, Polycarbonate etc
