High quality cutting plotter machine for mimaki printer

Name: High quality cutting plotter machine for mimaki printer
Brand: Graphtec
Availability: InStock

FOB Price

USD $16,584 - $41,460 / Piece

1 Piece(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port guangzhou
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Japan	Brand Name	Graphtec
Model Number	CE5000	Voltage	100 ~ 120 VAC,220 ~ 240 VAC,50/60 Hz
Cache Capacity	2MB	Paper Feed Width	60cm,120cm
Cutter Pressure	20 gf to 450 gf)(38 levels)	Cutting Width	Minimum: 85mm Maximum: 1346mm
Cutting Speed	100 cm/s	Driver	digital servo
Cutting Length	5m	Repeat Cutting	cutting
Size	1487 744 1194 mm

Product Description

High quality cutting plotter machine for mimaki printer

brand: Graphtec
size: 40cm,60cm,120cm
cut thick: 0.25mm

function: vinyl cutting plotter

weight:40Kg for 120cm width

Compatible cutter type: Graphtec Supersteel blades, 0.9MM and 1.5mm diameter

Product Description

Specifications:

Orginal Janpan Cutting Plotter Specification
Item	CE5000-120			CE5000-60
CPU	32-bit CPU
Construction	Microgrit Rollers, Moving Media
Driver systerm	Digital Servo Motor
Max cutting size	1213 mm × 50 m (47.7" × 164")			603 mm × 50 m (23.7" × 164")
Mechanical Resolution range	1194 mm × 5 m (47" × 16.4")			584 mm × 5 m (23" × 16.4")
Min Media width	85 mm (3.3")			50 mm (2")
Max Media width	1346 mm (53")			712 mm (28")
Max media thickness	0.25 mm (10 mil)
Max cutting speed	1000 mm/s (39.4 ips)(45°direction)			600 mm/s (24 ips)(In all directions )
Adjustable cutter pressure	20 ~ 450 gf ( Points 38 level )			20 ~ 300 gf ( Points 31 level )
Minimum character matrix	Max height about 5 mm (0.2")
Mechanical Resolution range	0.005 mm (0.0002")
Programmable resolution	GP-GLTM:0.1/0.05/0.025/0.01 mm
	HP-GL®:0.025 mm (0.001")
repeatability precision*1	0.1 mm/2 m (0.0039"/80") or better
Can loading pen number	1 pcs
Compatible cutter type	Graphtec Supersteel blades, 0.9MM and 1.5mm diameter
Compatible pen type	Graphtec water-based fibe-tip pen
Compatible Media	Vinyl film, Fluorescent, decal , light reflective(except high-luminosity),paint masking, banner, thermal transfer vinyl, flex, flock, ,pu,pvc image transfer media, vinyl print media, etc.
interface	Serial RS-232C/USB2.0 high speed ,IEEE-1284 Parallel (automatic identification)
Deta Buffer	2 MB
Comand modes	GP-GLTM/HP-GL® (selectable in Command menu)
the default number of cutting parameters	8 group, users can set any gronp.
display panel	16 character* LCD screen
power supply input	100 ~ 120 VAC,220 ~ 240 VAC,50/60 Hz
power consumption	Max 100 VA			Max 70 VA
	10 ~ 35 °C (50 ~ 95 oF),35 ~ 75 % RH (not-condensing)
Recommended Resolution Environment	16 ~ 32 °C (60 ~ 90 oF),35 ~ 70 % RH (not-condensing)
Dimensions W/Stand ( WDH)	1487 mm × 656 mm × 1188 mm2 (58.5" × 25.8" × 46.7")2			851 mm × 285 mm × 223 mm (33.5" × 11.2" × 8.7")
Equipment Weight W/stand	39.1 kg (86.2 lb.)*2			11.2 kg (24.7 lb.)
Accessories Including	power line		1pc
	Quick Start Manual		1pc
	Safe use manual		1pc
	User manual disc		1pc
	CB09UA cutter		1pc
	Cutting Master software		1pc
	SATA		1pc
	PHP32-CB09N Blade Holder		1pc
	Windows Drivers		1pc
	CE5000-120 Cutter Holder	1pc	CE5000-60 Cutter Holder		0pc

Features:

1. Economical

2. user-friendly

3. Optimum

4. good cutting quality

5. Multi-usage: Advertising label. The control panel. Phone beauty. Mobile phone buttons. The serial number label. Clothing cutting such as thermal transfer; Heat transfer T-shirt. Souvenirs. Glass products, car stickers. Labeling. Any shape infra-red positioning, suitable for cutting

The whole processing:
