Plexy Glass Laser Cutting Machine

Our laser machines are packed with plywood, We will package the machine with preservative film firstly, and then package the machine with plywood,at last we will fill foam in the space between the machine and the plywood. At last, we will enlace the wooden case with iron belts.

Specifications

JQ-1515 plexy glass laser cutting machine is a machine which utilizing laser to cut acrylic,MDF, wood, cloth, fabric,etc.

Plexy Glass Laser Cutting Machine

Performance Features:

1.      Configure high power laser tube.

2.      DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.

3.      Owns functions of restoring from power off, continuation on break point.

4.      Transmit files directly in Coreldraw, AutoCAD,etc.

5.      Adopt international linear rail, more precision.

Model	JQ-1515
Laser Power	80W/100W/130W
Laser Type	sealed CO2laser tube,water-cooled,10.6um
Work Area	1500 X 1500 mm
Cooling Type	Water-cooled and Protection System
Engraving Scanning Speed	0-60000 mm/min
Cutting Speed	0-1000mm/min
Laser Output Control	1-100% Software Setting
Smallest Character Engraving	English: 1.0X1.0 mm
Highest Scanning Precision	2500DPI
Power Supply	AC 110-220V±10%, 50-60Hz
Operating Temperature	0oC-45°C
Operating Humidity	5%-95%
Locating Precision	≤±0.01mm
Supported File Format	DSTPLTBMPDXFAI
Compatible Software	TAJIMACORELDRAWPHOTOSHOPAUTOCADAll  Type of AUTOCAD Software in cloth
Slope Engraving	360°Slope Can Be Designed Easily
Driving System	Stepper Electrical Motor
Package Dimension	3030*2020* 1300mm
Net Weight	1200 KGS
Gross Weight	1250 KGS
Optional Spare Parts	Up-down Worktable, Rotary System, Honeycomb Worktable
Removable Spare Parts	Laser Tube and Lens



Applicable Industries

Model Industry(construction models, aviation and navigation models and wooden toys),advertisement, decoration, arts and crafts, electronics and electronic appliances, etc.

Applicable Materials

Non-metal materials such as acrylic, wood planks(light planks),bamboo ware. double colored boards, paper, leather, shells, coconut shells, ox horns, resin, animal grease, ABS boards, lamp shade, etc.



Our laser machines could be customized according to your special requirements.
