1. Besides vacuum pump,this machine installs Roots Pump vacuum system,which speed up evacuation,
make limiting vacuum ≤ 5Pa,working vacuum ≤ 35Pa.
2. Large area three-dimensional flash distillation technique,advance dewatering and degassing system,which remove water and gas much quickly and completely.
3. Precise filtration system,high-quality filter element,multi-stage filtration with gradual precision,which help removing mechanical impurities in the oil.
4. After purification the breakdown voltage of transformer oil can reach up to 70KV.
5. Advanced double-infrared liquid automatic controller,pressure automatic-protector,which ensure long-term safe and reliable operation.
7. This machine can be operated both on-load and off-load.
8. Humanization design,low noise pump,deep purification and long-term free maintenance.
9. General type,Trailer-mounted type,Hermetical type,Flow meter etc. is available.
Parameters |
Unit |
ZYD-30 |
ZYD-50 |
ZYD-100 |
ZYD-150 |
ZYD-200 |
ZYD-250 |
ZYD-300 |
|
Flow |
L/min |
30 |
50 |
100 |
150 |
200 |
250 |
300 |
|
Working vacuum |
Mpa |
-0.08 ～ -0.099 |
|||||||
Working Pressure |
Mpa |
≤0.3 |
|||||||
Temperature Range |
℃ |
20 ～ 80 |
|||||||
Power |
380V/ 50Hz/ 3Phase( Or as per customer’s request) |
||||||||
Working Noise |
Db（A） |
75 |
75 |
75 |
80 |
80 |
80 |
80 |
|
Heating Power |
KW |
30 |
30 |
45 |
60 |
75 |
90 |
120 |
|
Total Power |
KW |
35.5 |
37.5 |
52.5 |
71.4 |
86.5 |
102.5 |
135 |
|
Inlet/Outlet |
mm |
φ25 |
φ32 |
φ42 |
φ50 |
φ50 |
φ60 |
φ60 |
|
Weight |
Kg |
600 |
800 |
1050 |
1400 |
1800 |
2000 |
2200 |
|
Overall |
Length |
mm |
1050 |
1100 |
1200 |
1450 |
1600 |
1800 |
1900 |
Width |
mm |
750 |
800 |
950 |
950 |
1100 |
1200 |
1200 |
|
Height |
mm |
1350 |
1400 |
1500 |
1650 |
1800 |
1900 |
1900 |
|
After Filtration | |||||||||
Breakdown Voltage |
KV |
＞70 |
|||||||
Water Content |
PPM |
＜5 |
|||||||
Gas Content |
% |
≤0.1% |
|||||||
Particle Size |
μ |
≤1 ～ 5(without free carbon) |
|||||||
Acid Value |
mgKOH/g ≤0.03 |
||||||||
