Specifications
DSP Controlling systemAdopting high THK Linear rail from Japan
High precision two-nut rolling ball screw from germany
Distinguish Features
· Stiff: integral cast-iron frame ,embedded linear ,much more stable and solid
· Accuracy :rolling ball screw from Germany ,two nut eliminating clearance ,advanced fixing mode of three bearings
· Strong :configured 2.2kw inverter-driven spindle motor cooled by water
· Superior :adopt the most advanced DSP controlling system
Application
· Strong functions ,easy operation ,sturdy ,durable ,reliable performance ,reasonable price ,wide application ;can be applied to process any wood products ,sign boards ,bill plates ,chest brands ,seals ,metal foil molds ,construction moulds ,instruments panel, woody products ,industrial moulds .Any metal or non-metal material can be processed ,for example ,iron ,copper ,aluminum ,plastic and wood plates etc .
Servo system (optional)
Dust collecting System (optional )
Vacuum System (optional )
Note:Any changes of technical parameters without notice
Performance Features :
Model | SD8070 | SD1212 | SD1218 | SD1325 | SD1630 | SD2030 |
|
| |||||||
Working Area | 700x800x90mm | 1200x1200x90mm | 1200x1800x90mm | 1250x2500x90mm | 1550x3000x90mm | 2000x3000x90mm |
|
| |||||||
Spindle Motor | 2.2KW inverter-driven motor cooled by water | 3KW |
| ||||
| |||||||
Engraving Speed | 6000-12000mm/min |
| |||||
| |||||||
Rotation Speed of Spindle | 6000-24000rpm |
| |||||
| |||||||
Engraving tool | 3.175mm,4mm,6mm(optional) |
| |||||
| |||||||
Format Dictate | HPGL,G-code |
| |||||
| |||||||
Ball Screw | Two-nut rolling ball screw from Germany |
| |||||
| |||||||
Resolution | 0.01mm |
| |||||
