Automatic Hand-held Optical Fiber Laser Welding Machine PE-W1000D

Descrition for Automatic Hand-held Optical Fiber Laser Welding Machine PE-1000D

 Laser, known as the stimulated emission of light amplification, the English full name: Light Amplification by Stimulate Emission of Radiation; referred to as Laser. It is a new light source, which has the coherence, monochrome, directional and high output power and other characteristics, is the other light can not match.
Laser welding is the use of laser beam excellent directional and high power density and other characteristics to work. Through the optical system to gather the laser beam in a small area, in a very short period of time, so that the welding is the formation of a highly concentrated local heat source area, so that the welding material melting and the formation of solid solder joints and welds.
PE-W1000D laser welding machine is YAG type pump source, the use of optical fiber laser welding machine. It is in the equipment shape, structure and suitable for the operation of the man-machine interface based on the effectiveness of human nature and work has a lot of new ideas.
The equipment adopts industrial integrated design, compact structure and beautiful, with a good beam mode, energy concentration, stable performance, the use of reliable, fast welding, wide range of welding, consumables long life and other characteristics, taking full account of Equipment in the mass production of various parameters, from the details to do the key parameters adjustable data show closed loop.

Power Function for Automatic Hand-held Optical Fiber Laser Welding Machine PE-1000D

 1) modular circuit program design, according to the actual application of dual lamp configuration parameters and light mode
2) based on industrial field data communication, to provide RS232 serial communication, to ensure a good anti-jamming capability, communication distance can reach 100M
3) 65536 color high-resolution 7-inch LCD display color screen, support for touch control
4) system alarm operation information integrity, to provide undercurrent, overcurrent, overload, phase, phase sequence error, water pressure limit, water temperature limit, radiator overheating and other protection, alarm prompt function can be displayed in real time more than 100 Troubleshooting information
5) with the corresponding interface circuit, to achieve 128 parameters of the non-stop soft switching and 64 groups of parameters of the hard switch (soft switch to software control switch, can be set in the touch control interface; hard switch to hardware control switch, Through the external logic to give the corresponding level to control)
6) Each group of laser processing can be at least 32 sections of the waveform of any set, each section provides current ramp mode movements, the system can save 100 groups of programs for users to call
7) through the operation of the user interface, the valve function can be set to start before the light out of the lead time and the delay after the delay time
8) Intelligent shutter control. Millisecond time delay time can be customized according to user needs to ensure complete shading
9) slow down the slow down control by the user to set each pulse current rise, slow down the amplitude and action starting point
10) can achieve real-time energy automatic feedback function, the energy of the light stabilized within 2% of the error
