YAG Type Hand-held Optical Fiber Laser Welding Machine PE-W500G
US$ 1,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
Perfect Laser
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Hand-held Optical Fiber Laser Welding Machine PE-W1000DUS$ 1,000 - 10,000MOQ: 1 Set -
Three-Phase Four Wire System Mold Repair Welding Machine PE-600DUS$ 1,000 - 10,000MOQ: 1 Set
-
Double Light Path Led Laser Welding Machine for Advertising Sinage Letter Making PE-W300IIUS$ 6,000 - 6,500MOQ: 1 Unit
-
Perfect Laser PE-W400II 400w Fiber China Stainless Steel Laser Welding MachineUS$ 4,000 - 10,000MOQ: 1 Unit
-
Perfect Laser PE-W300 300W Micro Laser Welding Machine Advertising Letter Welder With CEUS$ 4,900 - 6,800MOQ: 1 Set
Condition
New
Place of Origin
Hubei, China
Brand Name
Perfect Laser
Model Number
PE-W500G
Single Pulse Energy
90J
Pulse Width
0.1-20ms
Wavelength
1064 Nm
Focal Spot Diameter
0.1-2.0mm
Max. Output Power
16kw
Dimensions
750*1000mm
Usage
Welding
Power(W)
500W
Certification
CE, ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
YAG Type Hand-held Optical Fiber Laser Welding Machine PE-W500G
Contact:Nicole Skype:perfectlaser02 Email:sales02 at
Product Description
Description for YAG Type Hand-held Optical Fiber Laser Welding Machine PE-W500G
- Laser, known as the stimulated emission of light amplification, the English full name: Light Amplification by Stimulate Emission of Radiation; referred to as: Laser. It is a new light source, which has the coherence, monochrome, directional and high output power and other characteristics, is the other light can not match.
- Focus the laser to a pot , the power density on the focal plane can reach 105-1013w / cm2. Laser welding is the use of laser beam excellent directional and high power density and other characteristics to work. Through the optical system to gather the laser beam in a small area, in a very short period of time, so that the welding is the formation of a highly concentrated local heat source area, so that the welding material melting and the formation of solid solder joints and welds.
Features
Features for YAG Type Hand-held Optical Fiber Laser Welding Machine PE-W500G
- PE-W500G laser welding machine is YAG type pump source, the use of optical fiber laser welding machine. It is in the equipment shape, structure and suitable for the operation of the man-machine interface based on the effectiveness of human nature and work has a lot of new ideas.
- The equipment adopts industrial integrated design, compact structure and beautiful, with a good beam mode, energy concentration, stable performance, the use of reliable, fast welding, wide range of welding, consumables long life and other characteristics, taking full account of Equipment in the mass production of various parameters, from the details to do the key parameters adjustable data show closed loop.
Appliacations
Application for YAG Type Hand-held Optical Fiber Laser Welding Machine PE-W500G
Available on metallic materials (e.g. stainless steel, carbon steel, copper, titanium alloy, tungsten, molybdenum, etc.)
Technical Date
| Laser wavelength | 1064nm |
| Maximum output power | 500W |
| Laser Souce | YAG type pump source,Metal concentrator |
| Optical system | Imported Dielectric film |
| Laser pulse frequency | 1-100HZ(Continuously adjustable) |
| Laser pulse width(Continuously adjustable) | 0.1-20ms |
| Energy stability | ≤3% |
| Continuous working time | ≥16 Hours |
| Laser cooling | Water Cooling |
| Fiber length | 5m |
| Maximum power Consumption | 16KW |
| Power supply | Three-phase four wire AC ,380V,50Hz,≤20KVA |
| Air pressure | Interface, air / argon,0.7Pa |
Samples
Company Information
Contact
Perfect Laser Co., Ltd. (China)
Contact: Nicole / Sales Department
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Wuhan, Hubei, China(430200).
Tel: 0086-27-86791986 MP: 0086-13659886768 Fax: 0086-27-86775865
Skype: perfectlaser002
Whatsapp: 008613659886768
QQ: 1911800430
