20 years factory non metal co2 laser engraving cutting machine
Skype:perfectlaser005 Whatsapp/Mobile: 86 0136 5988 2898 Email: sales05 at
Company Introduce video: https://youtu.be/Ojo3XnAzRdM
Working video for PEDK-13090: https://youtu.be/WMZPXwkPmc8
Perfect Laser are 20 years laser industrial machine manufacturer and exporter
Certified with CE & ISO & TUV.
Free Technical Supporting Life-Long
24 Hours Online Service
Exported to more than 180 countries.
Received many good feedback from our clients.
Different working area: 4030,6040,9060,13090,160100,130180,160260/130250
Description of co2 laser engraving machine
with different working area/laser power, which can engrave/cut on acrylic, wood, fabric, cloth, leather, rubber plate, PVC, paper and other kinds of nonmetal materials with complex shapes. Our Laser Engraving Machine is widely applicable for advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing and other industries.
Application Fields of co2 laser engraving machine
Application Industry: Advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing and other industries.
Available Materials of co2 laser engraving machine
Advertisement material |
Acrylic engraving cutting, plastic engraving and cutting, PVC board engraving and cutting, rubber plate engraving, seal engraving, organic glass engraving, Plexiglas engraving, marble engraving, granite engraving, Gum engraving, EVA materials engraving, paper engraving and cutting. |
Wood material: |
Wood engraving and cutting, MDF engraving, plywood cutting, bamboo engraving. |
Garment material: |
Leather engraving and cutting, textile engraving, fabric engraving, cloth engraving, Shoes engraving, jeans engraving, carpet engraving and cutting, toy cutting, woolen cutting, denim engraving and cutting. |
Special Features of co2 laser engraving machine
1) Advanced LCD Touch Screen+ USB port+ DSP Offline Control, which can not only work without computer, but also connect to U disk, USB communication.
2) LCD Control System own 128M Big Memory, which can store files in the machine for engraving and cutting, compatible with AutoCAD, CorelDraw, Photoshop and some other kinds of graph disposal software.
3) Imported high precision linear guide rail and professional optical system, dustproof and lubricate, which improve the engraving quality and prolong machine lifetime.
4) Special Front and back running-through design, the unique door for the limitless engraved materials through.
5) Professional Honeycomb or Strip work table, which meet the needs of diversified laser procession;
6) Water Cooling System with Alarm Protection, adopt CW-3000 Water Chiller with temperature display, which can avoid over burning, to protect the water circulation from electricity-off.
7) Equipped with luxury Consumables, Imported Focus Lens and reflect mirror, Chinese Best Quality Laser Tube, 10000 hours Laser Tube and RF metal tube for your choose, makes high efficiency and steady.
8) High speed stepper subdivision driver control, numeral timing, simulation quantum control laser power, little error, repetition high precision, engrave 1×1mm little English character perfect.
9) Red Light Pointerrealizes the exact position without laser.
10) Matched Professional software is particularly designed and written for engraving and cutting, with high compatibility, support any computer operating system.
11) Optional Motorized up-down work table with Auto Focus Function, very good for precise focusing and different cutting depth requirement for lots of material;
12) Optional 3D Rotary System, engrave circumrotately 360 degree, applicable in column or cone work piece surface.
13) Optional Rolling and Automatic Feeding System, realize the long work piece automatically completely, such as one roller of cloth/fabric/leather/garment.
14) Optional Imported Ball Screw Rod, with high speed and accuracy, it is smoothly for laser head to move speedily and laser beam to reflect with high accuracy.
Technical Parameters of co2 laser engraving machine
Model |
PEDK-4030 |
PEDK-6040 |
PEDK-9060 |
PEDK-13090 |
PEDK-160100 |
PEDK-130250 |
PEDK-130180 |
PEDK-160260 |
|||||
Working Area |
400×300mm |
600×400mm |
900×600mm |
1300×900 mm |
1600×1000mm |
1300×2500mm |
1300×1800mm |
1600×2600mm |
|||||
Laser Power |
40W / 50W |
50W / 60W |
60W / 80W |
60W / 80W / 100W / 120W / 150W / 200W |
||
Laser Type |
Hermetic and Detached Co2 Laser Tube |
|||||
Engraving Speed |
1-60000mm/min |
|||||
Cutting Speed |
1-10000mm/min |
|||||
Repeat Location Accuracy |
± 0.0125mm |
|||||
Laser Power Controlling |
1-100% Manual Adjustment and Software Controlling |
|||||
Voltage |
220V(±10%) 50Hz |
|||||
Cooling Mode |
Water Cooling and Protect System |
|||||
Cutting Platform |
Professional Thickening Strip or Honeycomb Work Table |
|||||
Controlling Mode |
CNC Professional Control System |
|||||
Support Graphics Formats |
BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF Compatible HPG Order To Support DXF, WMF, BMP, DXT |
|||||
Power Controlling Mode |
Laser Energy Combining Movement Control System |
|||||
Control Software |
Original Perfect Laser’s Engraving & Cutting Software |
|||||
Training |
Video Training |
|||||
Guarantee |
12 month Guarantee Period |
|||||
Co2 Laser Engraving Cutting Machine
Perfect Laser Co2 laser cutting machine and laser engraving machine have 2 types, one is small size laser engraving machine with 600×400mm, 900×600mm, 1300×900mm, 1600×1000mm working areas. Another is flat bed laser size type fabric cutting machine with 1300×1800mm, 1300×2500mm, 1600×2600mm working areas. It has been widely used in the fields of ADs, garment industry for acrylic cutting, acrylic engraving machine, wood cutting, wood engraving.
We have different models, such as PEDK-9060, PEDK-13090, PEDK-160100, PEDK-130250 and so on. To choose best machine for you, please kindly check and tell us:
1>the exact material you want to work with? (acrylic, wood, rubber, marble, textile, fabric, leather, paper, etc)
2>The working size of the machine you demand? (max dimension of material, width*length, 600*400 mm-PEDK-6040 model, 900*600 mm-PEDK-9060 model, 1200*900 mm-PEDK-13090 model,...)
3>For the laser power, we need know the cutting depth you demand? (5 mm thick wood, 15 mm thick acrylic, etc, this will decide the laser power.)
4>Do you want to engrave on round surface too?
5>The destination sea port you desire? Then we can check the shipping cost for you.
Perfect Laser Co., Ltd. (China)In order to recommend suitable machine model for perfect laser engraving cutting solution ,please check below questions and kindly let me know:
1.What is the exact material you want to engrave/cut? (wood, acrylic, cloth, fabric, leather, rubber, paper, plastic, marble....)
2.What is the cutting thickness u need to cut on above materials?(max thickness, 3 mm, 6 mm, 15 mm, 20 mm....)
3.What is the working area you demand? (max dimension of material, 600*400 mm, 900*600 mm, 1300*900 mm,...)
Welcome to contact us for Perfect Laser engraving cutting solution !
