Product Details
Brand Name: | hongyuan | Place of Origin: | China | Model Number: | HYL-8 |
Type: | Other, Grain processing equipment | Use: | Other, cleaning/sieving/separeting grain |
Product Description
Single out clean cron cleaner grader machine
Product Description
Corn screening machine is suitable for small and medium-sized starveling, on-site to receive food screening directly throw food into the warehouse and grain piles. This machine belongs to the multi-purpose machinery such as corn, soybeans, wheat, replace the screen when you need, 8 to 14 tons per hour, select degree 99%
Portable clean grain cleaner can change according to the grain particle size screen mesh, suitable for corn, soybeans, wheat, rice, sunflower seeds and other grains. This machine is compared with other general grain screening machine, cleaning dust produced when food, greatly changed the cleaning sieve environment. The machine with centrifugal fan, dust catcher, close the wind discharger, total power is 7KW, mobile convenience, cleaning clarity can reach more than 90%, the cleaning quantities is: 10 tons/hour.
Model No. | Air Blower Motor | Sieving Machine Motor | Capacity | Machine Size(mm) | Weight |
HYL-8 | 4kw | 3kw | 8-14T/H | 2800*1350*1500 | 600kg |
Working Principle
Separation principle of vibrating screen is set according to the geometry characteristics of seed, seed varieties and species is different, the size is also different, choose changing sieve in different piece, can meet the requirements of separation.
Working Process
The cleaning sieve for three layers of the bottom of the screen, first through the first screening of the big screen in front of clutter and fine soil and small cleaning, have main blower prior to discharge of the air separation cleaning, clean up after another in the front of small grain machine to mass ejection at a distance, eventually achieve the grain of the mould and the grain containing small impurities.
Working Performance
Used to remove grain chaff of the leaf, shell, dust and wizened grain and other sundry. This machine has beautiful shape, compact structure, convenient movement, obvious dust removal efficiency of removing impurity, low energy consumption, the use of the advantages of simple and reliable, and screen mesh can according to user requirements any exchange, suitable for different varieties of materials.
.
Product Details
Name : Punch Plate Screen Mesh
Aperture Size : 5-12mm as per grain size
Material : Q235A Carbon Steel
Name : Air Blower
Motor Power : 4KW
Function : Blowing/Sorting/Separating Light Impurities out
Name : Winnowing Device
Features : Can working as a Winnower which throwing the grain into warehouse after sieving ,it make the grain further cleaner.
Name : Dust Bin
Feature : Collecting the dust impurities and discharged from the outlet which reduce the pollution for the environment.
Product Categories
Cleaning & Bagging
This machine's main task is to remove the impurity in the food, the final food outlet facilitate food bag, binning, storage.
Cleaning & Throwing
This machine's main task is to remove the impurity in the grain, the back is a throwing equipment, the cleaned grain after stroke can be according to the differences in the quality of the grain is more effective to eliminate mildew grain, separated particle size.
Packing & Delivery
Packing in standard fumigation ply wooden box.
Packing Size:3180mm(L)*1650mm(W)*1730mm(H)
If container is too tight, we will use PE film for packing or pack it according to customers special request.
