Handpick vegetable seeds air-and-screen cleaners equipment

Handpick vegetable seeds air-and-screen cleaners equipment

Product Description

Cleaning machine is mainly used in grains and nuts. In order to reach the index of agricultural products specifications and quality standards, need to clean up the material and grade. Clear refers to remove foreign material and impurity in the material; Grading refers to clean up after the material according to their size, shape, density and quality characteristics into level. Working principle and methods of the cleaning and classification work have a lot in common, is often asked in a finished device. Approved by the threshing device off and the separation device to isolate short rotor in mixed with broken, crushed stem, clever shell and dust and other small inclusions. Cleaning device's function is to separate mixtures of kernels, will other impurity discharge closed, to get clean grain.

Working principle

To clean up the food from large inlet feeding, cleaning machine by powder feeder, scatter food into powder box, material dispersed, dust removal fan for material dust removal for the first time at this time, the proportion of food into the sieve, sieve plate surface through the sieve proportion principle, the food is different from the weight of the impurities, separation, big impurities by big miscellaneous outlet, food and fine crushing grain and impurities on the second floor screen, dust dust removal fan again, fine crushed grain and impurities into the third layer, leakage and impurities separated from the second floor of food into the mouth.

Product Power

Product Usage

This machine is mainly used for wheat, corn, barley, soybeans, rice, camellia crops such as grain seed selection classification. Also for grain processing before cleaning equipment, grain and oil processing industry change different grain cleaning sieve can be; It is a multi-use of economical cleaning sieve extension.

Production process

1. Complete the cleaning impurity separation process for the first time; Surface impurities do reverse motion, collected by removing impurity ground dragon, grain under the gravity casting to move forward along the screen surface, into the classification of vibration filter screen surface in the first layer classification screening, food in the mixed material retained in the screen surface coarse impurity from coarse impurity outlet conversion, grain particles through the sieve surface into the second screen surface.

2. The second layer of the sieve plate aperture and basic equal grain particles, and thus make the small tiny impurities, crushed grain and immature grain through the screen surface, in the third layer of screen surface, selected after full particles retained in the screen surface under the vibration of the sieve body straight forward movement, packaging or transport by net grain outlet granary.

3. The third layer mesh less than half of the grain particles, grain particles can be retained in the screen surface, can through the layer of the sieve surface material is tiny impurities and grain debris and excluded by a fine noise channel of fine miscellaneous mouth closed, can random bagging.

Packing & Delivery

Due to the large volume weight, the type of grain cleaner for nude.

Related Product

Name: Mobile Screw Conveyor

Description: It is one kind of granule or powder filling and feeding device for bagging or sieving machine in horizontal or inclined angle way; With lifting structure, it is easily up down for different height.

Name: Mobile Belt conveyer

Description: DY Series mobile belt conveyor is one kind of continuous mechnical handling and loading unloading equipment with feature of high efficiency and durability,safety and reliability.
