Help CenterHighway Construction-- Plastic Spraying Guardrail Plate
Related Products
Specifications
Highway construction-- Plastic spraying guardrail platematerial: Q235 Q345 steel plate
Application:The traffic road block
Specifications
Plastic spraying guardrail plate
material: Q235 Q345 steel plate
Application:The traffic road block
Product introduction: guardrail plate it using soil base, column, beam deformation to absorb impact energy, and force is out of control vehicle changing direction, return to normal driving direction, prevent the vehicle out, in order to protect the vehicle and the passenger, reduce the loss caused by accidents.
Color: galvanized silvery white, plastic spraying, green, white, blue, etc.
According to the waveform can be divided into double wave form guardrail and threewave form the barriers.
According to surface treatment can be divided into hot dipped galvanized waveform guardrail and galvanized coating.
According to the set location can be divided into roadside guardrail and median guardrail.
Highway waveform guardrail plate according to the grades of collision avoidance can be divided into class A and class S.Belongs to enhanced s-class guardrail, suitable for roadside particularly dangerous road use, grade A for special roads.Commonly used roadside wave beam guardrail according to the grades of collision avoidance can be divided into B, A, SB, SA, SS grade 5.
Structure form code | |
Gr | wave beam guardrail GRBS - prevention of wave beam guardrail |
Grd | combination waveform guardrail |
Gc | cable guardrail |
Gw | concrete guardrail |
Gwb | basic concrete guardrail |
Gwm | modified concrete guardrail |
Collision avoidance level code | |
A | side outline A level |
S | roadside s-class |
Am | median grade A |
Sm | median s-class |
Embedding condition code | |
E | buried in soil |
Em | the central zone of concrete guardrail, interlock in grassroots E1, roadside concrete guardrail, embedded in the base |
E2 | roadside concrete guardrail, connected to the lower structure |
B | embedded in the concrete foundation |
R | concrete guardrail by force reinforced with the base connection |
