Best Price for 2013 Newly Produced Vertical Type Composite Crusher

Specifications

great crushing ratio, energy consumption, stable operation, simple structure, convenient maintenance and operation

Best Price for2013 Newly Produced Vertical Type Composite Crusher from China Professional Factory





Composite crusher is a newly developed crushing machine that can do coarse grinding or fine crushing, which is mainly used in medium scale cement plants to break cement raw material and clinker for cement plant production line. It also applies to iron ore, sandstone, gypsum, blast furnace slag, coal gangue, lump coal and other medium hard ore crushing. It is featured by great crushing ratio, energy consumption, stable operation, simple structure, convenient maintenance and operation.





Technical Parameters



Model	Feeding Size(mm)	Discharge Size(mm)	Production Capacity(t/h)	Shaft Speed(r/min.)	Motor Power(kw)	Dimension (L*W*H) (mm)
PFL-750	≤100	≤3-5 60-90%	10-20	934	22	2100x1200x1700
PFL-1000	≤120	≤3-5 60-90%	20-40	769	37	2600x1400x1900
PFL-1250	≤150	≤3-5  60-90%	40-70	530	75	2800x1600x2100
PFL-1500	≤180	≤3-5 60-90%	70-100	495	132	3100x1900x2200
PFL- 1750	≤200	≤3-5 60-90%	130-190	424	160	3710x2360x2390
PFL-2000	≤220	≤3-5 60-90%	100-160	370	185	4100x2660x2620
