Specifications
small hydraulic cone crusherGood product size
Good stability, High reliability
Easy to clean chamber
Easy operation
small hydraulic cone crusher
For Russia Customer
A Symons Cone Crusher can crush materials with middle to very high hardness, materials such as, metal ore,granite, basalt, limestone, sandstone and much much more.
If your mining or aggregate business runs 24 hours a day and needs high reduction with large capacity the Symons type cone crusher can be optimized to meet your demands.
Advantages of Symons Cone Crusher
1. high crushing ratio, high efficiency, high capacity, low operating cost, easy adjustment and economical operation.
2. Our symons cone crusher has exported to many countries, such as Chile, Oman, Philippines, Tanzania etc.
3. It is made of high quality raw material and has reasonable structure design. So it has longer running performance and even granularity.
4. The middle and large size symons cone crusher adopts hydraulic clear chamber. That reduces its down time.
Application of Symons River Rock Crusher
It is widely used in the industries of metallurgy, building material, road construction, chemical engineering and silicate. Symons cone crusher is suitable for crushing all kinds of ores and rocks with hardness of medium or above.
Models & Parameters
| specifications | style | chamber type | broken cone main diameter(mm) | Adjustable Range of Output Size(mm) | mouth edge feeding size in the min recommended discharging port(mm) | max feeding size(mm) | capacity(t/h) | motor power(kw) | weight(kg) | overall dimension(L×W×H)(mm) |
| 900 | PSGB-0910 | standard thin | 914 | 9-22 | 102 | 85 | 45-91 | 75 | 9980 | 2656×1636×2241 |
| PSGB-0917 | standard thick | 13-38 | 1775 | 150 | 59-163 | |||||
| PSGB-0918 | standard thicker | 25-38 | 178 | 150 | 118-163 | |||||
| PSGB-0904 | Short head thin | 3-13 | 41 | 35 | 27-90 | 10530 | ||||
| PSGB-0906 | Short head medium | 3-16 | 76 | 65 | 27-100 | |||||
| PSGB-0907 | Short head thick | 6-19 | 102 | 85 | 59-129 | |||||
| 1300 | PSGB-1313 | standard thin | 1295 | 13-31 | 137 | 115 | 109-181 | 160 | 22460 | 2983×1866×3156 |
| PSGB-1321 | Standard medium | 16-38 | 210 | 178 | 132-253 | |||||
| PSGB-1324 | standard thick | 19-51 | 241 | 205 | 172-349 | |||||
| PSGB-1325 | standard thicker | 25-51 | 259 | 220 | 236-358 | |||||
| PSGD-1306 | Short head thin | 3-16 | 64 | 54 | 36-163 | 22590 | ||||
| PSGD-1308 | Short head medium | 6-16 | 89 | 76 | 82-163 | |||||
| PSGD-1310 | Short head thick | 8-25 | 105 | 89 | 109-227 | |||||
| PSGD-1313 | Short head thicker | 16-25 | 133 | 113 | 209-236 | |||||
| 1600 | PSGB-1620 | standard thin | 1676 | 16-38 | 209 | 178 | 181-327 | 220 | 43270 | 3941×2954×3771 |
| PSGB-1624 | Standard medium | 22-51 | 241 | 205 | 258-417 | |||||
| PSGB-1626 | standard thick | 25-64 | 269 | 228 | 299-635 | |||||
| PSGB-1636 | standard thicker | 38-64 | 368 | 313 | 431-630 | |||||
| PSGD-1607 | Short head thin | 5-13 | 70 | 60 | 90-209 | 43870 | ||||
| PSGD-1608 | Short head medium | 6-19 | 89 | 76 | 136-281 | |||||
| PSGD-1613 | Short head thick | 10-25 | 133 | 113 | 190-336 | |||||
| PSGD-1614 | Short head thicker | 13-25 | 133 | 113 | 253-336 |
