Help Center2014 Steel Casting Type Small Basalt Crusher Equipment for Stone Quarry
Related Products
-
Powerful Primary Vibrating Screen 2YK1545 for Gravel Coarse SelectingUS$ 9,999 - 10,000MOQ: 1 Set -
China Made Very Large Jaw Crusher for Large Mountain Stone CrushingNegotiableMOQ: 1 Set
-
2014 Gold Ore Mining Small Ball Mill With Fair PriceNegotiableMOQ: 1 Set
-
Powerful Vertical Blast Hole Drilling Machine for SaleNegotiableMOQ: 1 Set
-
China Portable Track Drill KY100 for SaleNegotiableMOQ: 1 Set
Specifications
small basalt crusher equipment;500x750mm feed mouth;
primary crusher for rock crushing;
Steel welded frame;
ISO standard
We are an experienced stone crusher engineering company that has been in the stone crushing & screeing equipment field for many years. Welcome to visit our factory at your convenience! We warmly welcome you. Please kindly send your inquiry over about your request, we will do the best solution for you with our best offer.
A jaw crusher uses compressive force for breaking of particle. This mechanical pressure is achieved by the two jaws of the crusher of which one is fixed while the other reciprocates. A jaw or toggle crusher consists of a set of vertical jaws, one jaw is kept stationary and is called a fixed jaw while the other jaw, called a swing jaw, moves back and forth relative to it, by a cam or pitman mechanism, acting like a class II lever or a nutcracker.
The volume or cavity between the two jaws is called the crushing chamber. The movement of the swing jaw can be quite small, since complete crushing is not performed in one stroke. The inertia required to crush the material is provided by a weighted flywheel that moves a shaft creating an eccentric motion that causes the closing of the gap.
Jaw crushers are heavy duty machines and hence need to be robustly constructed. The outer frame is generally made of cast iron or steel. The jaws themselves are usually constructed from cast steel. They are fitted with replaceable liners which are made of manganese steel, or Ni-hard (a Ni-Cr alloyed cast iron).
Unique crushing and screening equipment is designed for maximum production capacity. We offer optimum solutions for quarry, mining or recycling, stationary or mobile. We can enhance your old existing plants, deliver effective solutions and turnkey installations. We also supply single crushers and screens, as well as key components and a wide range of spares.
The below are standard models for your choices.
PE900x1200
PE750x1060
PE600x900
PE500x750
PE400x600
PE250x400 PE150x250
Jaw Crusher inVietnam (200t/h rock crusher line)
Jaw Crusher in Philippines (100-120t/h river stone quarry line)
Jaw Crusher in Cameroon (200t/h stone crushing production line )
