Low Cost Economical Type Crawler Rig for Africa Mining

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai Qingdao etc
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Brand Name	Kaishan
Model Number	KY100J	Usage	Ore
Power(W)	20.2KW	Dimension(LWH)	4100x2030x2020
Weight	3.1t	Certification	ISO
Warranty	15 months	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

blast hold drilling rig, crawler drilling machine, borehole drilling machine, small crawler driller, small wagon drill

Low Cost Economical Type Crawler Rig for Africa Mining

It is widely used in quarry, railway, road, water and electricity, open-pit mines and construction work site to do deep or medium-deep rock hole drilling operations. Woring with the air compressor and the impactor(DTH hammer), it can drill horizontal, vertical, inclined blast hole, pre-hole and anchor bolt holes.

Specifications of Crawler Drill KY100J

Rock Rigidity: f=6-20

Dia. of hole: 80-105 mm

Optimum Drilling Depth: 20 m

Working Pressure: 0.5-0.7 Mpa

Air Consumption: ≥10m³/min.

Rotation Speed: 0-65 rpm

Torque: 983 N•m

Lift power: 15KN

Rod specification: 60x2000 mm

Gradeability: 30°

Ground Clearance: 254 mm

Walking Speed: 2.0 Km/h

Dimensions: 4100x2030x2020mm

Weight: 3100 kg

Drive System: ZS1125GM(20.2Kw 2200r/min)
