Low Investment Crawler Wagon Drill for Blast Hole Drilling
- Shanghai Qingdao etc
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Rotary Drilling Rig | |
| Power Type | Diesel | Brand Name | Kaishan | |
| Model Number | KY100J | Usage | Ore | |
| Power(W) | 20.2KW | Dimension(L*W*H) | 4100x2030x2020 | |
| Weight | 3.1t | Certification | ISO | |
| Warranty | 15 months | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
blast hold drilling rig, crawler drilling machine, borehole drilling machine, small crawler driller, small wagon drill
Low Investment Crawler Wagon Drill for Blast Hole Drilling
It is widely used in quarry, railway, road, water and electricity, open-pit mines and construction work site to do deep or medium-deep rock hole drilling operations. Woring with the air compressor and the impactor(DTH hammer), it can drill horizontal, vertical, inclined blast hole, pre-hole and anchor bolt holes.
Specifications of Crawler Drill KY100J
Rock Rigidity: f=6-20
Dia. of hole: 80-105 mm
Optimum Drilling Depth: 20 m
Working Pressure: 0.5-0.7 Mpa
Air Consumption: ≥10m3/min.
Rotation Speed: 0-65 rpm
Torque: 983 N•m
Lift power: 15KN
Rod specification: 60x2000 mm
Gradeability: 30°
Ground Clearance: 254 mm
Walking Speed: 2.0 Km/h
Dimensions: 4100x2030x2020mm
Weight: 3100 kg
Drive System: ZS1125GM(20.2Kw 2200r/min)
