Radial Drilling Machine
|
Z3080×25 |
Z3063X20A |
Max drilling dia (mm) |
80 |
63 |
Spindle axis to column (mm) |
500~2500 |
450~2050 |
Column dia (mm) |
550 |
450 |
Spindle taper (mm) |
MT6 |
MT5 |
Spindle travel (mm) |
450 |
400 |
Spindle speed range (r/min) |
16~1250 |
20~1600 |
Spindle speed steps |
16 |
16 |
Spindle feed range (mm/r) |
0.04~3.2 |
0.04~3.2 |
Feed steps |
16 |
16 |
Spindle nose to base (mm) |
550~2000 |
400~1600 |
Work table (mm) |
1000×800×560 |
950×630×500 |
base (mm) |
3530×1400×300 |
2900×1250×250 |
Machine dimension (mm) |
3730×1400×3790 |
3110×1250×3150 |
Motor power (kW) |
7.5 |
5.5 |
G.w./n.w. (kg) |
15000/11000 |
8000/7000 |
Packing size (cm) |
416×165×248 382×163×170 |
347×147×235 |
|
Z3040×16/1,Z3050×16/1,ZQ3050×20/1 |
Max drilling dia (mm) |
40,50,50 |
Spindle axis to column (mm) |
350~1600,350~1600,350~2000 |
Column dia (mm) |
350 |
Spindle taper (mm) |
MT4,MT5,MT5 |
Spindle travel (mm) |
315 |
Spindle speed range (r/min) |
25~2000 |
Spindle speed steps |
16 |
Spindle feed range (mm/r) |
0.04~3.2 |
Feed steps |
16 |
Spindle nose to base (mm) |
350~1250,320~1220,320~1220 |
Work table (mm) |
630X500X500 |
base (mm) |
2400X1000X200 |
Machine dimension (mm) |
2500X1060X2650 |
Motor power (kW) |
3,4,4 |
G.w./n.w. (kg) |
3900/3500,3900/3500,3950/3550 |
Packing size (cm) |
260×112×260,260×112×260,300×112×260 |
