SRD3012A Single Channel Oscilloscope + Signal Generator + Serial Center + Multimeter + Recorder

Shanghai Total Industrial Co., Ltd.
SRD3012A Single Channel Oscilloscope + Signal Generator + Serial Center + Multimeter + Recorder thumbnail-1
SRD3012A Single Channel Oscilloscope + Signal Generator + Serial Center + Multimeter + Recorder photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
ShowRange
Model Number:
SRD3012A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name ShowRange
Model Number SRD3012A

Features:

-New ultra-thin appearance design, small volume, light weight, convenient carrying
- Color TFTLCD display, 400*272 resolution, waveform display more clear, stable
-Ultra low power consumption, single battery can work for 5 hours
-support USB storage device, waveform screenshot saved
-Having the edge trigger function, can automatically detect support (50Hz - 60MHz)
-Support time and voltage cursor
- support, English menu display, select English button
-To display a variety of styles: color, black and white display
-Support automatic shutdown function and power saving mode: time can be set
-Backlight brightness adjustable
-With 6000 count digital multimeter function

SRD3012A Single channel oscilloscope + Signal generator + Serial Center + Multimeter + Recorder

SRD3012A

 The real-time sampling rate

 250MSa/S

 Channel

 1 analog channel; 1 digital channel(It can only display high-low level, can't display waveform.)

 Bandwidth

 30MHz  (frequency 60MHz) measured data

The vertical resolution

 8 bits

 Vertical sensitivity

 10mV-5V(Probe 1X); 100mV-50V(Probe 10X); 1V-500V(Probe 100X),(1,2,5 Stepping)

The vertical accuracy

 +/- 3%

 The input impedance

 1MΩ 25pF

 Input coupling

 DC, AC

 Display mode

 YT

 Input voltage

 40V(x1);400V(x10); 4000V(x100)

 The time base

 10ns-50ms(1,2.5,5 Stepping); 100ms-5s(Scan)

 The storage depth

 16k

Trigger Mode

Automatic, normal and single

Trigger Type

The rising edge, falling edge

Automatic detection

Support(50Hz-60MHz)

Measurement:

 The peak to peak value, duty cycle, frequency, cycle, max value, min value

 Cursor

 Time, voltage

 Screen

 4.3 inch   16 bit true color   TFT 400*272

 Multimeter

The full scale reading

 6000 count

 DC voltage

 60.00mV, 600.0mV, 6.000V, 60.00V, 600.0V, 1000V.

 AC voltage

 60.00mV, 600.0mV, 6.000V, 60.00V, 600.0V, 750V.

 DC current

 60.00mA/600.0mA, 6.000A/10.00A.

 AC current

 60.00mA/600.0mA, 6.000A/10.00A.

 Resistance

 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ, 60.00MΩ.

 Capacitor

 40.00nF, 400.0nF, 4.000μF, 40.00μF, 400.0μF, 4000μF(30sec.).

Diode

 0V~2.0V.

On-off detecting

  in 600Ω gear detection, buzzer when less than 30 Ω

The signal generator

 Frequency

 (Sine wave: 1Hz - 20MHz);  (square wave: 1Hz - 5MHz); (Triangle wave/Oblique wave: 1Hz - 1MHz)

 Duty ratio

 0% - 100%

 Amplitude

 100mV - 4V

 Offset

 +/- (0V - 2V)

Serial Center

 Baud rate

 115200 - 1200

 Data bits

 8, 9

 Parity bit

 NO ,ODD, EVEN

 Stop bit

 1, 0.5, 2, 1.5

 Hex

 10, 16

 Recorder

 It can record a group of waveforms per 1 second, the longest can be 10 mins.

 Time base

 100ms - 5s
