SRD2023 Single Channel Oscilloscope + Signal Generator

Shanghai Total Industrial Co., Ltd.
SRD2023 Single Channel Oscilloscope + Signal Generator thumbnail-1
SRD2023 Single Channel Oscilloscope + Signal Generator photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
ShowRange
Model Number:
SRD2023
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name ShowRange
Model Number SRD2023

Features:

-New ultra-thin appearance design, small volume, light weight, convenient carrying
- color TFTLCD display, 320*240 resolution, waveform display more clear, stable
-Ultra low power consumption, single battery can work for 5 hours
- support USB storage device, waveform screenshot saved
Having the edge trigger function, can automatically detect support (50Hz - 40MHz)
-Support time and voltage cursor
- support, English menu display, select English button
-To display a variety of styles: color, black and white display
-Support automatic shutdown function and power saving mode: time can be set
- backlight brightness adjustable
-With Signal generator Sine wave (1Hz - 5MHz); the other (1Hz-1MHz)

SRD2023 Single channel oscilloscope + Signal generator

Input



Input coupling

AC, DC

Channel

1 analog channel; 1 digital channel(It can only display high-low level, can't display waveform.)

Display mode

Y-T

The input impedance

1MΩ 25pF

The maximum input voltage

40V(Probe X1);220V, 400V(Probe X10);4000V(Probe X100)

Probe attenuation

1X,10X

Attenuation setting

1X,10X,100X

Signal acquisition system



Sampling method

Real time sampling

The storage depth

2K

Acquisition mode

Sampling

Vertical system



Vertical sensitivity

10mV-5V(Probe 1X);100mV-50V(Probe 10X);1V-500V(Probe 100X) (1,2.5,5 Stepping)

The vertical accuracy

+/-3%

The vertical resolution

8bit

Bandwidth

20MHz

Horizontal system



The real-time sampling rate

200 MSa/s

Horizontal scanning range

10nS/div-5S/div

Triggering system



Trigger Mode

Automatic, normal and single

Trigger Type

The rising edge, falling edge

Automatic detection

Support(50Hz-40MHz)

Measurement system



Cursor measurement

Support time and voltage

Measuring method

Manual

Measurement

The peak to peak value and frequency

Equipment



Screen

3.2 inch, 16 bit true color, TFT, 320*240

Battery

3000+mA Lithium battery (support 5 hours of continuous work)

size

202*100*35(mm)

Digital channel

200 MSa/s

 Signal generator

Frequency

Sine wave (1Hz - 5MHz); the other (1Hz-1MHz)

Duty ratio

0% - 100%

Range

100mV - 4V

Offset

+/-(0V -2V)
