SRD2012S Single Channel Oscilloscope + Multimeter

Shanghai Total Industrial Co., Ltd.
SRD2012S Single Channel Oscilloscope + Multimeter thumbnail-1
SRD2012S Single Channel Oscilloscope + Multimeter photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
ShowRange
Model Number:
SRD2012S
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name ShowRange
Model Number SRD2012S

Features:

-New ultra-thin appearance design, small volume, light weight, convenient carrying
-Color TFTLCD display, 320*240 resolution, waveform display more clear, stable
-Ultra low power consumption, single battery can work for 5 hours
-Support USB storage device, waveform screenshot saved
Having the edge trigger function, can automatically detect support (50Hz - 40MHz)
-Support time and voltage cursor
-Support, English menu display, select English button
-To display a variety of styles: color, black and white display
-Support automatic shutdown function and power saving mode: time can be set
-Backlight brightness adjustable
-With Signal generator Sine wave (1Hz - 5MHz); the other (1Hz-1MHz)

Multimeter Technical Specifications:

Full-scale reading: 6000 count
DC voltage: 60.00mV/600.0mv/6.000v/60.00v/600.0v/1000v
AC voltage: 60.00mV/600.0mv/6.000v/60.00v/600.0v/750v
Resistance measurement:600.0Ω/6.000KΩ/60.00kΩ/

600.0kΩ/6.000mΩ/60.00mΩ
Capacitance measurement:40.00nF/400.0nF/

4.000uF/40.00uF/400.0uF/4000uF(30Sec)
Off detection: Detect in 600.0Ω range, the buzzer will alarm if less than 30Ω
Diode measurements: 0v-2.0v

SRD2012S Single Channel oscilloscope + multimeter



Single Channel Oscilloscope Technical Specifications:

Input



Input coupling

AC, DC

Channel

1

Display mode

Y-T

The input impedance

1MΩ 25pF

The maximum input voltage

40V(Probe X1);220V, 400V(Probe X10); 4000V(Probe X100)

Probe attenuation

1X,10X

Attenuation setting

1X,10X,100X

Signal acquisition system



Sampling method

Real time sampling, random sampling

The storage depth

2K

Acquisition mode

Sampling, peak detect

Vertical system



Vertical sensitivity

10mV-5V(Probe 1X);100mV-50V(Probe 10X); 1V-500V(Probe 100X)(1,2.5,5 Stepping)

The vertical accuracy

+/-3%

The vertical resolution

8bit

Bandwidth

25MHz

Horizontal system



The real-time sampling rate

200 MSa/s

Horizontal scanning range

10nS/div-5S/div

Triggering system



Trigger Mode

Automatic, normal and single

Trigger Type

The rising edge, falling edge

Automatic detection

Support(50Hz-40MHz)

Measurement system



Cursor measurement

Support time and voltage

Measuring method

Manual

Measurement

The peak to peak value and frequency

Equipment



Screen

3.2 inch, 16 bit true color, TFT, 320*240

Battery

2000+mA Lithium battery (support 5 hours of

continuous work)

size

202*100*35(mm)

Digital channel

200 MSa/s
