Inductive Elevator Bucket for Chain Conveyor

Specifications

It's suitable for chain conveyors mixed by vertical and horizontal transmission. It's widely used in the seed and food processin

  Inductive Elevator Bucket





Material: HDPE, Nylon





Its suitable for chain conveyors mixed by vertical and horizontal transmission. Its widely used in the seed and food processing industry.







Specification Chart



Model	A(mm)	B(mm)	C(mm)	Capacity L
LL 6323	632	236	120	11.00
LL 4013	406	133	69	2.00
LL 3921	390	218	120	4.80
LL 3821	380	213	125	4.80
LL 3319	330	198	103	4.0
LL 3219	330	200	110	3.19
LL 3115	310	150	75	2.30
LL 2619	260	190	78.5	2.34
LL 2412	246	122	60	1.20



If you need specific product standard, please contact us at any time.







Features:

1.High intensity, wear-resistance, corrosion-proof, with longer life span than steel buckets.
2.Light weight, extend the life span of the bucket, reduce the energy consuming of the elevators.
3.Good pliability , low product damage percent of only 1.
4.No spark caused in operation, avoid the possibility of dust exploration.
5.Clean discharge, wide temperature applications.



Technical Index:

1.Method of Manufacture : Injection molded.
2.Drilling: Free of charge. Special drilling is offered according to customers demand. (For detailed drilling specifications, pls refer to the related specification chart).

3.Installation:Norway flat head elevator bolts, flanged bolt, sabre-tooth bolt, and belt bolt.
4.Sanitary Standard: FDA approvalnon--toxic and no causticity itselt, suitable for food industry.
