Help CenterXT-M100 Hot Air Seam Sealing Machine for Rainwear
Related Products
XT-M100 hot air seam sealing machine for rainwear.
Technical Parameter:
Power consumption :220vac50hz1800w abt
Speed :2.5-20m/min infinitey variable
Compressed air :50psi(min)
Upper roller lift :30mm
Working roller height :150mm
Fudible band width :Standard 14mm-22mm other optional
Heater power :1700w of special heating elements
Pressure roller width :25.4mm standard with options for plain point engraved and striped roller.
Heat comtrol :Infinitely variable up to 700°C
Size :Width 550mm length 1400mm height 1690mm
Sema skip prevention :Adjustable delays on both nozzle in,drive start and drive stop,nozzle out.
Application:
used for waterproof fabric sewing like PVC,PU/polyeaster/nylon fabric ,it's the first choose product for some manufactories.
2.Characteristic
micro-computer control,easily operation,it can still work for 24hours and it's very convenient.It reduces the hard work to the worker
3.Features:
One:
IC monitoring and interlocking on nozzie pressure,temperatore and motor speed status protect the machine against misrse an ensore the quality of the final product.
Two:
Scree multi-functionaldisplay unit provide clear indications on fabric speed,operaling status and alarming.
Three:
Fully automatic temperature controller with both set point and process value indications.
Four:
Advance design:sealing temperature,speed and status display controlled by individual micro controllers
