Home > Industrial Equipment & Components > Power Transmission Parts > Gearbox > Double Screw Extruder Warm Gear Box
Double Screw Extruder Warm Gear Box
US$ 4,500 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Putuoshan
Model Number:
Many types
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Single Screw Extruder Gear BoxUS$ 400 - 6,000MOQ: 1 Set -
Single Screw Extruder GearboxesUS$ 450 - 5,000MOQ: 1 Set
-
Single Plastic Screw Extruder Warm Gear Box PartsUS$ 350 - 3,000MOQ: 1 Set
-
Vertical Single Screw Warm Gear BoxUS$ 420 - 6,625MOQ: 1 Set
-
ZLYJ200 Gearbox for Single Screw Plastic Extruder With Oil Pump and ChllierUS$ 300 - 10,000MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Putuoshan
Model Number
Many types
Gearing Arrangement
Other, For conical twin screw and barrel
Specifications
Gear box for conical twin screw and barrel extruderGear box for the double screw and barrel extruder .
The main technical performance table in the gearbox process are:
|
SZ45 |
SZ50 |
SZ55 |
SZ65 |
SZ80 |
SZ92 |
|
Input speed max r/min |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
Output speed max r/min |
44.8 |
37.8 |
37.5 |
39.1 |
37.7 |
40 |
Input power kw |
18.5 |
22 |
30 |
37 |
55 |
110 |
Uniaxial torque output N.m |
1972 |
2779 |
3820 |
4518 |
6786 |
13130 |
Axis angle distribution |
2°40' |
2°58'12" |
2°36'14" |
2°11'16" |
2°0'18" |
1°52'3.64" |
Connect spline size |
8-48×42×8 |
8-48×46×9 |
6-60×53×14 |
8-65×56×10 |
8-72×62×12 |
10-98×92×14 |
